02 |
|
Hydr. cylinder |
1 |
InternBDB: 929 275 40 | InternKon: 932 481 40 / 1
|
355-4280e |
|
|
03 |
909 352 40
|
Piping, assy. l.h. fig-nos. 05-31 |
1 |
InternBDB: E-ST | InternKon: 932 481 40 / 2
|
|
|
|
05 |
905 922 40
|
Clamp clip |
1 |
InternKon: 909 352 40 / 1
|
|
|
|
06 |
909 549 40
|
Spanner |
1 |
InternKon: 909 352 40 / 2
|
|
|
|
07 |
897 758 40
|
Clamp Set |
1 |
InternKon: 909 352 40 / 3
|
|
|
|
08 |
909 559 40
|
Weld on plate |
1 |
InternKon: 909 352 40 / 4
|
|
|
|
09 |
121 674 40
|
Round bar steel |
2 |
InternBDB: 10x50 | InternKon: 909 352 40 / 5
|
|
|
|
10 |
513 303 98
|
Connecting block 2" |
2 |
InternBDB: 133x110 / SAE-L-Block 2 /414 | InternKon: 909 352 40 / 6
|
|
|
|
11 |
793 276 73
|
Pipe assy.Ш 65 |
1 |
InternBDB: 909 553 40 | InternKon: 909 352 40 / 7
|
|
|
|
12 |
793 277 73
|
Pipe assy.Ш 65 |
1 |
InternBDB: 909 552 40 | InternKon: 909 352 40 / 8
|
|
|
|
13 |
505 440 98
|
Half clamp |
6 |
InternBDB: S-4-R-65 /3015 | InternKon: 909 352 40 / 9
|
|
|
|
14 |
534 008 99
|
Cover plate |
3 |
InternBDB: S-DP-A-4 /3015 | InternKon: 909 352 40 / 10
|
|
|
|
15 |
509 310 98
|
Locking plate |
1 |
InternBDB: SI 6 WN 011 839 99 | InternKon: 909 352 40 / 11
|
|
|
|
16 |
504 448 98
|
Flange |
4 |
InternBDB: FE 6500-32/6 WN 011 747 99 | InternKon: 909 352 40 / 12
|
|
|
|
17 |
504 449 98
|
Collar ring |
3 |
InternBDB: KO-6580-32 WN 011 747 99 | InternKon: 909 352 40 / 13
|
|
|
|
18 |
504 461 98
|
Collar ring |
3 |
InternBDB: K-6580-32 WN 011 747 99 | InternKon: 909 352 40 / 14
|
|
|
|
19 |
385 243 40
|
Quadring |
5 |
InternBDB: 58,1x2,79x3,2 NBR 90 | InternKon: 909 352 40 / 15
|
|
|
|
20 |
319 323 99
|
Bolt |
8 |
InternBDB: M 20x90 / 912 10.9 | InternKon: 909 352 40 / 16
|
|
|
|
21 |
308 414 99
|
Bolt |
8 |
InternBDB: M 20x130 / 931 10.9 | InternKon: 909 352 40 / 17
|
|
|
|
22 |
307 808 99
|
Bolt |
2 |
InternBDB: M 12x50 / 933 8.8 | InternKon: 909 352 40 / 18
|
|
|
|
23 |
308 613 99
|
Bolt |
2 |
InternBDB: M 12x110 / 931 8.8 | InternKon: 909 352 40 / 19
|
|
|
|
24 |
308 615 99
|
Bolt |
4 |
InternBDB: M 12x130 / 931 | InternKon: 909 352 40 / 20
|
|
|
|
25 |
334 600 99
|
Nut |
6 |
InternBDB: M 12 / 985 | InternKon: 909 352 40 / 21
|
|
|
|
26 |
334 601 99
|
Nut |
2 |
InternBDB: M 16 / 985 | InternKon: 909 352 40 / 22
|
|
|
|
27 |
340 469 99
|
Washer |
2 |
InternBDB: Ш 17 / 140HV /125 | InternKon: 909 352 40 / 23
|
|
|
|
28 |
793 278 73
|
Pipe assy.Ш 65 |
1 |
InternBDB: 913 994 40 | InternKon: 909 352 40 / 24
|
|
|
|
29 |
504 898 98
|
Flange |
2 |
InternBDB: FE-6500 WN 011 747 99 | InternKon: 909 352 40 / 27
|
|
|
|
30 |
502 538 98
|
Bolt |
4 |
InternBDB: M 20x150 / 931 | InternKon: 909 352 40 / 26
|
|
|
|
31 |
504 662 98
|
Nut |
4 |
InternBDB: M 20 /934 | InternKon: 909 352 40 / 25
|
|
