BACKHOE STICK 4,5M | PC4000-6 S/N 08195 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

PC4000-6 S/N 08195

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Options
?	903 030 40	Stick assy.	1
?	903 000 40	Stick ( weldment )	1	InternKon: 903 030 40 / 1
?	905 272 40	Freeze-in bushing	2	InternBDB: 342/298x251 \| InternKon: 903 030 40 / 2
?	905 273 40	Flanged bush	2	InternBDB: 302/258x217 BN 333x18 \| InternKon: 903 030 40 / 3
?	905 274 40	Flanged bush	2	InternBDB: 323/198x177 BN 263x18 \| InternKon: 903 030 40 / 4
?	905 275 40	Freeze-in bushing	2	InternBDB: 172/148x201 \| InternKon: 903 030 40 / 5
?	905 213 40	Freeze-in bushing	2	InternBDB: 203/169x201 \| InternKon: 903 030 40 / 6
?	907 031 40	Seal ring	2	InternBDB: 300/7,5x4 \| InternKon: 903 030 40 / 7
?	907 020 40	Seal ring	4	InternBDB: 150/4x4 \| InternKon: 903 030 40 / 8
?	907 022 40	Seal ring	4	InternBDB: 170/7x4 \| InternKon: 903 030 40 / 9
?	908 664 40	Ring	2	InternBDB: 430x330x15 \| InternKon: 903 030 40 / 10
?	907 374 40	Clevis	2	InternBDB: C14 VC-Sch 4,0 / 7984331 RUD \| InternKon: 903 030 40 / 11
?	907 433 40	Link oval	2	InternBDB: A40 15T Globus \| InternKon: 903 030 40 / 12
?	904 561 40	Pin with plate	2	InternBDB: 505 \| InternKon: 909 574 40 / 3
?	887 374 40	Shackle	2	InternKon: 909 574 40 / 4
?	504 576 98	Bolt	4	InternBDB: M 30x130 / 931 \| InternKon: 909 574 40 / 5
?	340 472 99	Washer	4	InternBDB: 31 / 125 \| InternKon: 909 574 40 / 6
?	909 522 40	Pin with plate	2	InternBDB: 150x465 \| InternKon: 909 358 40 / 3
?	905 749 40	Shackle	2	InternBDB: 187 \| InternKon: 909 358 40 / 4
?	307 886 99	Bolt	2	InternBDB: M 24x55 / 933 \| InternKon: 909 358 40 / 5
?	002 027 79	Washer	2	InternBDB: 77 \| InternKon: 909 358 40 / 6
