PIPING - BACKHOE CYLINDER R.H. | PC4000-6 S/N 08195

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

PC4000-6 S/N 08195

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Options	Reference
?		Hydr. cylinder	1	InternBDB: 929 275 40 \| InternKon: 932 482 40 / 1	355-4280e
?	909 353 40	Piping, assy. r.h. fig-nos. 10-38	1	InternKon: 932 482 40 / 2
?	909 522 40	Pin with plate	1	InternKon: 932 482 40 / 3
?	905 749 40	Shackle	1	InternKon: 932 482 40 / 4
?	307 886 99	Bolt	2	InternBDB: M24x55 8.8 DIN00933 \| InternKon: 932 482 40 / 5
?	002 027 79	Lock washer	2	InternBDB: 77 KES01643 \| InternKon: 932 482 40 / 6
?	905 922 40	Clamp clip	1	InternKon: 909 353 40 / 1
?	909 549 40	Spanner	1	InternKon: 909 353 40 / 2
?	897 758 40	Half clamp	2	InternKon: 909 353 40 / 3
?	909 559 40	Weld on plate	1	InternKon: 909 353 40 / 4
?	121 674 40	Round bar steel	2	InternKon: 909 353 40 / 5
?	513 303 98	Connecting block 2	2	InternKon: 909 353 40 / 6
?	796 980 73	Pipe assy. r.h. Ш 65	1	InternBDB: 948 431 40 \| InternKon: 909 353 40 / 7
?	769 937 73	Pipe assy. r.h. Ш 65	1	InternBDB: 909 509 40 \| InternKon: 909 353 40 / 8
?	505 440 98	Clamp Set	6	InternBDB: S-4-R-65 DIN03015 \| InternKon: 909 353 40 / 9
?	534 008 99	Cover plate	3	InternBDB: S-DP-A-4 DIN03015 \| InternKon: 909 353 40 / 10
?	509 310 98	Locking plate	1	InternBDB: S / 6 \| InternKon: 909 353 40 / 11
?	504 448 98	Flange	4	InternBDB: FE 6500-32/6 WN01174799 \| InternKon: 909 353 40 / 12
?	504 449 98	Collar ring	2	InternBDB: KO-6580-32 \| InternKon: 909 353 40 / 13
?	504 461 98	Collar ring	2	InternBDB: K-6580-32 \| InternKon: 909 353 40 / 14
?	385 243 40	Quadring	4	InternBDB: 58,1x2,79x3,2 NBR 90 \| InternKon: 909 353 40 / 15
?	319 323 99	Bolt	8	InternBDB: M20x90 DIN00912 \| InternKon: 909 353 40 / 16
?	308 414 99	Bolt	8	InternBDB: M20x130 10.9 DIN00931 \| InternKon: 909 353 40 / 17
?	307 808 99	Bolt	2	InternBDB: M12x50 DIN00933 \| InternKon: 909 353 40 / 18
?	308 613 99	Bolt	2	InternBDB: M12x110 DIN00931 \| InternKon: 909 353 40 / 19
?	308 615 99	Bolt	4	InternBDB: M12x130 DIN00931 \| InternKon: 909 353 40 / 20
?	334 600 99	Nut	6	InternBDB: M12 DIN00985 \| InternKon: 909 353 40 / 21
?	334 601 99	Nut	2	InternBDB: M16 DIN00985 \| InternKon: 909 353 40 / 22
?	340 469 99	Washer	2	InternBDB: Ш17/140HV \| InternKon: 909 353 40 / 23
?	796 981 73	Pipe assy. r.h. Ш 65	1	InternBDB: 913 994 40 \| InternKon: 909 353 40 / 24
?	504 898 98	Flange	2	InternBDB: FE-6500 WN01174799 \| InternKon: 909 353 40 / 25
?	502 538 98	Bolt	4	InternBDB: M20x150 10.9 DIN00931 \| InternKon: 909 353 40 / 26
?	504 662 98	Nut	4	InternBDB: M20 10 DIN00934 \| InternKon: 909 353 40 / 27
