01 |
358 678 40
|
Hydr.-pump, assy. |
1 |
InternBDB: Hamworthy FZ 2216 C5 B 26 A AT-Nr. 668 844
|
|
|
|
02 |
757 349 73
|
Shaft seal |
1 |
InternBDB: P 9097 00 0201
|
|
|
|
|$$3 |
753 520
|
Circlip |
1 |
InternBDB: P 8515 00 0291
|
|
|
|
03 |
988 887
|
Housing |
1 |
InternBDB: P 0222 00 0121
|
|
|
|
04 |
988 899
|
Seal ring |
1 |
InternBDB: P 8395 00 0140
|
|
|
|
05 |
988 904
|
Needle bearing |
4 |
InternBDB: P 8340 00 0111
|
|
|
|
06 |
988 900
|
Support ring |
2 |
InternBDB: P 8991 00 0071
|
|
|
|
07 |
998 239
|
Gasket |
2 |
InternBDB: P 9421 00 0111
|
|
|
|
08 |
998 240
|
Plate |
1 |
InternBDB: P 7751 22 0111
|
|
|
|
09 |
992 857
|
Gear set |
1 |
InternBDB: K 0622 16 0071
|
|
|
|
10 |
998 241
|
Plate |
1 |
InternBDB: P 7751 22 0121
|
|
|
|
11 |
988 889
|
Dowel pin |
2 |
InternBDB: P 9093 00 0101
|
|
|
|
12 |
|
Housing
These parts are not sold
separately |
1 |
|
|
|
|
13 |
988 902
|
Lock washer |
4 |
InternBDB: P 8252 00 0121
|
|
|
|
14 |
992 858
|
Bolt |
4 |
InternBDB: P 8117 00 0061
|
|
|
|
15 |
757 744 73
|
Gasket |
1 |
InternBDB: P 9350 00 0061
|
|
|
|
16 |
992 860
|
Bush |
1 |
InternBDB: P 7275 00 0521
|
|
|
|
17 |
992 859
|
Thread pin |
4 |
InternBDB: P9152 00 0091
|
|
|
|
18 |
|
Cover
These parts are not sold
separately |
1 |
|
|
|
|
19 |
992 888
|
Disk |
4 |
InternBDB: P8253 00 0101
|
|
|
|
20 |
988 894
|
Nut |
4 |
InternBDB: P9149 00 0081
|
|
|
|
21 |
753 521
|
Shaft seal |
1 |
InternBDB: P9319 00 0061
|
|
|
|
|$$23 |
692 910
|
Seal kit
fig-nos: 02,04,06,07 and 21 |
-2 |
InternBDB: K0122 02 0011
|
|
|
|
|$$24 |
973 833 73
|
Repair kit
consist. of seal kit and
fig-nos: 05,08 and 10 |
-2 |
InternBDB: K1122 02 0011
|
|
