01 |
492 505 40
|
Engine-Saver - bracket |
2 |
|
|
|
|
02 |
440 986 40
|
Rubber block support |
4 |
InternBDB: Phoenix 781 091-60
|
|
|
|
03 |
340 463 99
|
Disc |
4 |
InternBDB: 6,4 /125
|
|
|
|
04 |
346 499 99
|
Lock washer |
4 |
InternBDB: 6 /128
|
|
|
|
05 |
332 110 99
|
Nut |
4 |
InternBDB: M 6 /985
|
|
|
|
06 |
055 103 40
|
Cable shoe, red |
2 |
InternBDB: He. u. Bu. 50.252.118
|
|
|
|
07 |
255 745 40
|
Rubber grommet |
2 |
InternBDB: Bosch 3130 558 000
|
|
|
|
08 |
502 609 98
|
Cable
Bulk ware, state length
required |
-2 |
InternBDB: 1І-blau
|
|
|
|
09 |
431 169 40
|
Water temperature transmitter |
1 |
InternBDB: Motometer 642.007.1009
|
|
|
|
10 |
339 918 99
|
Seal ring |
1 |
InternBDB: 26x32 /7603
|
|
|
|
11 |
461 390 40
|
Drain valve |
1 |
InternBDB: Roelex
|
|
|
|
12 |
490 586 40
|
Drain hose |
1 |
InternBDB: Roelex
|
|
|
|
13 |
005 853 98
|
Clamp |
4 |
InternBDB: 1 S 33x12 010 422 99
|
|
|
|
14 |
534 020 99
|
Welding plate |
3 |
InternBDB: E 5 011 839 99
|
|
|
|
15 |
502 143 98
|
Half clamp |
6 |
InternBDB: H-C 5/32 011 839 99
|
|
|
|
16 |
340 405 99
|
Washer |
6 |
InternBDB: 6,4 /433
|
|
|
|
17 |
319 136 99
|
Screw |
6 |
InternBDB: M6x50 /912
|
|
|
|
18 |
168 422 40
|
Hose (colourless) DN 25x1500 lg. (glasklar)
Bulk ware, state length
required |
2 |
InternBDB: Weil PVC-glasklar 33x25
|
|
|
|
19 |
515 562 40
|
Oil pressure gauge |
1 |
InternBDB: Motometer 675.002.1012
|
|
|
|
20 |
621 547 40
|
Plug |
2 |
InternBDB: Deutsch HD 16-9-96-S
|
|
|
|
21 |
621 548 40
|
Socket |
2 |
InternBDB: Deutsch HD 14-9-96-P
|
|
|
|
22 |
621 698 40
|
Plug connection 1-2 mmІ |
18 |
InternBDB: 0460-215-16141
|
|
|
|
23 |
621 699 40
|
Female contact |
18 |
InternBDB: 0460-209-16141
|
|
|
|
24 |
431 117 40
|
Cover |
1 |
|
|
|
|
25 |
461 350 40
|
Magnetic pickup
(load limitation) |
1 |
InternBDB: Cummins 303 4572 5/8-18 UNF
|
|
|
|
26 |
634 404 40
|
Strain relief |
2 |
InternBDB: HD 18-009
|
|
|
|
27 |
414 899 40
|
Rpm-sensor |
1 |
InternBDB: Cummins 303 9524 3/4-16 UNF
|
|
