02 |
502 194 98
|
Bolt
Standard |
6 |
InternBDB: 5/8-11 UNC x 2" /10.9
|
|
|
|
02 |
506 016 98
|
Bolt
Cold weather design |
6 |
InternBDB: 5/8-11 UNC x 2" /10.9 kaltz
|
|
|
|
03 |
|
Coupling |
1 |
InternBDB: 440 081 40 | InternKon: 386 903 40 / 6
|
090-3664 |
|
|
05 |
|
Joint shaft |
1 |
InternBDB: 324 481 40 | InternKon: 386 909 40 / 8
|
090-7003 |
|
|
06 |
534 058 99
|
Bolt
Standard |
20 |
InternBDB: M18 x 40 / 933 10.9 | InternKon: 386 909 40 / 4
|
|
|
|
06 |
504 304 98
|
Bolt
Cold weather design |
20 |
InternBDB: M18 x 40 / 933 10.9 kaltz | InternKon: 386 909 40 / 4
|
|
|
|
07 |
389 890 40
|
Covering |
1 |
InternKon: 389 897 40 / 1
|
|
|
|
08 |
389 882 40
|
Bracket |
1 |
InternKon: 389 897 40 / 2
|
|
|
|
09 |
389 883 40
|
Bracket |
1 |
InternKon: 389 897 40 / 3
|
|
|
|
10 |
389 884 40
|
Bracket |
1 |
InternKon: 389 897 40 / 4
|
|
|
|
11 |
389 885 40
|
Bracket |
1 |
InternKon: 389 897 40 / 5
|
|
|
|
12 |
366 589 40
|
Clamp |
2 |
InternKon: 389 897 40 / 6
|
|
|
|
13 |
338 011 99
|
Wing nut |
4 |
InternBDB: M 8 / 315 | InternKon: 389 897 40 / 7
|
|
|
|
14 |
346 510 99
|
Lock washer |
12 |
InternBDB: 8 / 128 | InternKon: 386 903 40 / 8
|
|
|
|
15 |
332 111 99
|
Nut |
4 |
InternBDB: M8 / 934 | InternKon: 386 903 40 / 9
|
|
|
|
16 |
307 750 99
|
Bolt |
4 |
InternBDB: M8 x 15 / 933 | InternKon: 386 903 40 / 11
|
|
