01 |
239 441 40
|
Pressure Accumulator assy |
1 |
InternBDB: Fa. Hydac SB 330-10A1 /
|
|
|
|
01 |
269 067 40
|
Pressure Accumulator (TT) assy. |
1 |
InternBDB: Fa. Hydac SB330.10A1 665A-330
|
|
|
|
02 |
999 645
|
Blase, assy. |
1 |
|
|
|
|
03 |
999 642
|
Cap |
1 |
InternKon: 114-1880/01 / 6
|
|
|
|
04 |
999 643
|
Cap nut |
1 |
InternKon: 114-1880/01 / 5
|
|
|
|
05 |
999 644
|
Nut |
1 |
InternKon: 114-1880/01 / 4
|
|
|
|
06 |
999 549
|
Valve cartridge |
1 |
InternKon: 114-1880/01 / 3
|
|
|
|
07 |
502 185 98
|
O-ring |
1 |
InternBDB: 7 x 2,5 /90 011 745 99 | InternKon: 114-1880/01 / 7
|
|
|
|
08 |
|
Blase
These parts are not sold
separately |
1 |
InternKon: 114-1880/01 / 2
|
|
|
|
09 |
999 646
|
Typeplate |
1 |
InternKon: 114-1880/01 / 8
|
|
|
|
10 |
999 541
|
Oil valve body complete |
1 |
|
|
|
|
11 |
999 542
|
Valve disc assy |
1 |
|
|
|
|
12 |
999 647
|
Valve disc |
1 |
InternKon: 114-1880/01 / 10
|
|
|
|
13 |
999 648
|
Valve spring |
1 |
InternKon: 114-1880/01 / 13
|
|
|
|
14 |
999 649
|
Oil valve body |
1 |
InternKon: 114-1880/01 / 9
|
|
|
|
15 |
999 650
|
Resilient bush |
1 |
InternKon: 114-1880/01 / 11
|
|
|
|
16 |
999 651
|
Securing nut |
1 |
InternKon: 114-1880/01 / 12
|
|
|
|
17 |
339 884 99
|
Seal |
1 |
InternBDB: 14x18x1,5/ 7603 | InternKon: 114-1880/01 / 20
|
|
|
|
18 |
999 652
|
Breather screw |
1 |
InternKon: 114-1880/01 / 19
|
|
|
|
19 |
999 543
|
Ring |
1 |
InternKon: 114-1880/01 / 14
|
|
|
|
20 |
999 546
|
Chamber ring |
1 |
InternKon: 114-1880/01 / 15
|
|
|
|
21 |
367 123 99
|
O-ring |
1 |
InternBDB: 80x5 /90/ 3770 | InternKon: 114-1880/01 / 16
|
|
|
|
22 |
999 653
|
Spacer |
1 |
InternKon: 114-1880/01 / 17
|
|
|
|
23 |
999 654
|
Grooved nut |
1 |
InternKon: 114-1880/01 / 18
|
|
|
|
24 |
502 186 98
|
O-ring |
1 |
InternBDB: 48x3 /90 011 745 99 | InternKon: 114-1880/01 / 27
|
|
|
|
25 |
999 544
|
Adapter |
1 |
InternBDB: 2"/ 1 1/2" | InternKon: 114-1880/01 / 25
|
|
|
|
26 |
692 063
|
Filler and test equipment |
1 |
InternBDB: FPS 250 1/0 G1
|
|
|
|
27 |
792 482 73
|
Support ring |
1 |
InternBDB: 238 848 | InternKon: 114-1880/01 / 23
|
|
|
|
|$$29 |
999 545
|
Seal kit
fig-no: 07,17,20,21,24, 27 |
-2 |
InternBDB: E-ST
|
|
|
|
|$$30 |
692 062
|
Repair kit
consist. of fig-nos. 02,19
and seal kit |
-2 |
InternBDB: E-ST
|
|
