01 |
907 740 40
|
Control block assy. |
1 |
InternBDB: Rexroth MO-3476-01 R901043950
|
|
|
|
02 |
|
Housing |
1 |
InternBDB: MH4-MO-52H10/DTHPPP11ss | InternKon: R901043950 / 5
|
|
|
|
03 |
766 848 73
|
Cover |
4 |
InternBDB: 160 442/R900160442 | InternKon: R901043950 / 6
|
|
|
|
05 |
794 404 73
|
Piston |
3 |
InternBDB: R901052428 | InternKon: R901043950 / 8
|
|
|
|
06 |
794 405 73
|
Piston |
1 |
InternBDB: R901052440 | InternKon: R901043950 / 9
|
|
|
|
07 |
754 576
|
Plate |
8 |
InternBDB: MO-52-10 /300 549/R900300549 | InternKon: R901043950 / 17
|
|
|
|
08 |
756 344 73
|
Seal ring |
16 |
InternBDB: 26,3x33,5x2,2 /003 340
|
|
|
|
09 |
319 275 99
|
Bolt |
64 |
InternBDB: M12x50 /10.9 / 912 | InternKon: R901043950 / 20
|
|
|
|
10 |
173 495 40
|
Plug |
1 |
InternBDB: M48x2 /34191340 | InternKon: R901043950 / 228
|
|
|
|
11 |
794 377 73
|
Cover |
1 |
InternBDB: 043907/R901043907 | InternKon: R901043950 / 16
|
|
|
|
12 |
794 373 73
|
Cover |
3 |
InternBDB: 036842/R901036842 | InternKon: R901043950 / 11
|
|
|
|
13 |
006 852 98
|
O-ring |
8 |
InternBDB: 110,72x3,53 014 447 | InternKon: R901043950 / 38
|
|
|
|
14 |
511 554 98
|
Eyebolt |
3 |
InternBDB: M 20 /580 | InternKon: R901043950 / 24
|
|
|
|
15 |
|
Pressure relief valve |
1 |
InternBDB: 461 498 40 / 381 589/ R900381589 | InternKon: R901043950 / 15
|
090-0404 |
|
|
16 |
794 406 73
|
Spring assy. |
4 |
InternBDB: R901043906 | InternKon: R901043950 / 14
|
|
|
|
17 |
794 407 73
|
Spring assy |
3 |
InternBDB: R900833624 | InternKon: R901043950 / 13
|
|
|
|
18 |
768 917 73
|
Spring assy |
1 |
InternBDB: 896 356/R900896356 | InternKon: R901043950 / 18
|
|
|
|
19 |
793 812 73
|
O-ring |
4 |
InternBDB: 009 243 | InternKon: R901036842 / 100
|
|
