01 |
913 572 40
|
Multi-station manifold block assy. |
1 |
|
|
|
|
02 |
896 720 40
|
Multi-station manifold block |
1 |
InternBDB: Westa RAP-S 3/8-06 - 1/2"-04 | InternKon: 913 572 40 / 1
|
|
|
|
03 |
551 467 40
|
Pressure relief valve |
1 |
InternBDB: Rexroth ZDB 6-YB 2-4X/50 | InternKon: 913 572 40 / 2
|
|
|
|
04 |
490 079 40
|
Non-return valve |
2 |
InternBDB: Rexroth Z1S6P1-3X/V | InternKon: 913 572 40 / 3
|
|
|
|
05 |
655 698 40
|
4/2 Directional spool valve |
2 |
InternBDB: Vickers DG 4V-3-OA-M-KUP3-H7-60 EN 125 | InternKon: 913 572 40 / 4
|
|
|
|
06 |
515 119 40
|
Pressure control valve |
1 |
InternBDB: Rexroth STD-0095 | InternKon: 913 572 40 / 5
|
|
|
|
08 |
514 342 98
|
Bolt |
4 |
InternBDB: M5x110 /912 10.9 | InternKon: 913 572 40 / 7
|
|
|
|
09 |
321 472 99
|
Bolt |
4 |
InternBDB: M5x70 /912 10.9 | InternKon: 913 572 40 / 8
|
|
|
|
10 |
319 174 99
|
Bolt |
4 |
InternBDB: M5x40 /912 10.9 | InternKon: 913 572 40 / 10
|
|
|
|
11 |
513 252 98
|
Bolt |
4 |
InternBDB: M5x50 /912 10.9 | InternKon: 913 572 40 / 9
|
|
|
|
12 |
972 193
|
O-ring |
-2 |
InternBDB: 9,25x1,78
|
|
|
|
13 |
348 648 40
|
Seal |
1 |
InternBDB: Hischmann GDM 3-17
|
|
|
|
14 |
515 210 40
|
Cube plug |
1 |
InternBDB: Murr 246 340
|
|
|
|
15 |
763 697 73
|
Compression spring |
2 |
InternBDB: 012 275
|
|
|
|
16 |
763 698 73
|
Taper |
2 |
InternBDB: 167 635
|
|
|
|
17 |
511 072 98
|
O-ring |
2 |
InternBDB: 008 205 9x1,5
|
|
|
|
18 |
763 700 73
|
Support ring |
2 |
InternBDB: 013 064
|
|
|
|
19 |
763 696 73
|
Bushing |
2 |
InternBDB: 167 822
|
|
|
|
20 |
763 695 73
|
Housing |
2 |
InternBDB: 166 399
|
|
|
|
21 |
763 701 73
|
Housing |
1 |
InternBDB: 682 893
|
|
|
|
22 |
763 702 73
|
Plate |
2 |
InternBDB: 127 443
|
|
|
|
23 |
757 932 73
|
Pressure relief valve |
1 |
InternBDB: DB 6 K2-4x/y
|
|
|
|
24 |
324 634 40
|
3 Way pressure control valve |
1 |
InternBDB: Rexroth DREP6 A-1X/25A24 N9 4KM | InternKon: 913 572 40 / 6
|
|
