PC5500-6E S/N 15060

Komatsu parts book diagram for PC5500-6E S/N 15060: TANK LINES - SLEW GEAR

01 01 02 04 05 05 05 05 05 06 06 06 07 08 08 08 08 09 1 1 1 1 1 1 1 1 1 1 1 1 1 1 10 10 10 11 11 11 12 12 13 14 15 15 16 16 16 16 16

	#	Part Number	Partname	Quantity	Options	Reference
	01	374 416 99	Socket	2	InternBDB: L 10 A-G 1/4 /3901 \| InternKon: 933 961 40 / 33
	02	516 173 98	Socket	1	InternBDB: L 10 /3944 \| InternKon: 933 961 40 / 35
	04	516 158 98	Socket	1	InternBDB: L 15 /3942 \| InternKon: 918 858 40 / 64
	05	643 995 40	Hose DN 08x3500	1	InternBDB: 240 DOL 10 / DOL 10 - 90 \| InternKon: 918 858 40 / 35
	06	513 256 98	Hose DN 08x980	1	InternBDB: 240 DOL 10/DOL 10 (51727498 ohne Kunstst.schutz) \| InternKon: 933 961 40 / 19
	07	516 156 98	Socket	1	InternBDB: L 10 /3942 \| InternKon: 933 961 40 / 34
	08	374 415 99	Socket	3	InternBDB: L 42 B-M /3901 \| InternKon: 918 858 40 / 67
	09	516 163 98	Socket	1	InternBDB: L 42 /3942 \| InternKon: 918 858 40 / 106
	10	516 154 98	Hose assy.DN 40x850	1	InternBDB: DOL 42 /DOL 42-90 \| InternKon: 918 858 40 / 29
	11	516 155 98	Hose assy.DN 40x1000	1	InternBDB: DOL 42 /DOL 42-45 \| InternKon: 918 858 40 / 30
	12	374 431 99	Socket	2	InternBDB: L 28 E-M /3901 \| InternKon: 918 858 40 / 107
	13	374 407 99	Socket	1	InternBDB: L 15 E-M /3901 \| InternKon: 918 858 40 / 65
	14	374 408 99	Socket	2	InternBDB: L 18 B-M /3901 \| InternKon: 918 858 40 / 66
	15	621 127 40	Socket	2	InternBDB: RED 28/18-PL /OMD \| InternKon: 918 858 40 / 72
	16	512 323 98	Hose assy.DN 16x2980	2	InternBDB: DOL 18 /DOL 18-90 \| InternKon: 918 858 40 / 31

Komatsu PC5500-6E S/N 15060 parts catalog PDF

TANK LINES - SLEW GEAR (515-1849e) in PC5500-6E S/N 15060. Diagram image and parts list.
