01 |
358 677 40
|
Hydr.-motor, assy. |
1 |
InternBDB: Hydromatik A2F M63/61 W-PAB 03 408 525 AT-Nr. 668 847
|
|
|
|
02 |
753 588
|
Housing |
1 |
InternBDB: 410 035 | InternKon: 211.18.25.42 / 03
|
|
|
|
03 |
319 124 99
|
Screw |
2 |
InternBDB: M10x25 /912 | InternKon: 211.18.25.42 / 07
|
|
|
|
04 |
343 855 99
|
Lock washer |
6 |
InternBDB: 10 /7980 | InternKon: 211.18.25.42 / 08
|
|
|
|
05 |
319 431 99
|
Screw |
4 |
InternBDB: M10x60 /912 | InternKon: 211.18.25.42 / 10
|
|
|
|
06 |
753 589
|
Connection plate |
1 |
InternBDB: 408 517 | InternKon: 211.18.25.42 / 04
|
|
|
|
07 |
971 096
|
O-ring |
1 |
InternBDB: 78,97x3,53 235-7507 | InternKon: 211.18.25.42 / 06
|
|
|
|
08 |
344 777 99
|
Parallel pin |
1 |
InternBDB: 5 M6x12 /7-ST | InternKon: 211.18.25.42 / 05
|
|
|
|
09 |
754 465
|
Transmission, assy.
fig-nos: 10,17-30 |
1 |
InternBDB: 408 522 | InternKon: 211.18.25.42 / 01
|
|
|
|
10 |
754 468
|
Transmission, assy.
fig-nos: 11-16 |
1 |
InternBDB: 418 286
|
|
|
|
11 |
753 591
|
Control plate |
1 |
InternBDB: 409 990 | InternKon: 201.18.07.92 / 02
|
|
|
|
12 |
753 606
|
Cylinder |
1 |
InternBDB: 409 989 | InternKon: 201.18.07.92 / 01
|
|
|
|
13 |
754 467
|
Spring plate |
1 |
InternBDB: 417 558 | InternKon: 201.18.07.92 / 06
|
|
|
|
14 |
753 596
|
Cup spring |
4 |
InternBDB: 402 352 | InternKon: 201.18.07.92 / 07
|
|
|
|
15 |
753 597
|
Trunnion |
1 |
InternBDB: 409 992 | InternKon: 201.18.07.92 / 03
|
|
|
|
16 |
754 466
|
Piston with piston ring |
7 |
InternBDB: 417 824 +2x 156 195 | InternKon: 201.18.07.92 / 04
|
|
|
|
17 |
753 599
|
Screw, burnished |
7 |
InternBDB: M5x16 /7985 153 617 | InternKon: 201.18.07.10 / 20
|
|
|
|
18 |
754 469
|
Withdrawal plate |
1 |
InternBDB: 417 825 | InternKon: 201.18.07.10 / 07
|
|
|
|
19 |
753 602
|
Disk |
1 |
InternBDB: 409 994 | InternKon: 201.18.07.10 / 05
|
|
|
|
20 |
754 470
|
Drive shaft with bearing set
with fig-nos: 21-23,27 |
1 |
InternBDB: 419 765 | InternKon: 201.18.07.10 / 02
|
|
|
|
21 |
|
Roller bearing
These parts are not sold
separately |
1 |
InternBDB: T7 FC 050 DIN ISO 355 156 194 | InternKon: 201.18.07.10 / 10
|
|
|
|
22 |
|
Race
These parts are not sold
separately |
1 |
InternBDB: 408 443 | InternKon: 201.18.07.10 / 03
|
|
|
|
23 |
|
Roller bearing
These parts are not sold
separately |
1 |
InternBDB: 320 09 /720 | InternKon: 201.18.07.10 / 11
|
|
|
|
24 |
753 607
|
Shim ring 85x105x0,1 |
2 |
InternBDB: DIN 988 152 831 | InternKon: 201.18.07.10 / 17
|
|
|
|
25 |
341 518 99
|
Shim ring 85x105x0,3 |
1 |
InternBDB: DIN 988 084 592 | InternKon: 201.18.07.10 / 18
|
|
|
|
26 |
972 199
|
O-ring |
1 |
InternBDB: 98,02x3,53 241-7507 | InternKon: 201.18.07.10 / 15
|
|
|
|
27 |
|
Groove nut
These parts are not sold
separately |
1 |
InternBDB: 156 021 | InternKon: 201.18.07.10 / 09
|
|
|
|
28 |
975 304
|
Shaft seal
No field repair item |
1 |
InternBDB: 40x55x7-NB 827 SK 152 916 | InternKon: 201.18.07.10 / 14
|
|
|
|
29 |
754 471
|
Cover
No field repair item |
1 |
InternBDB: 408 442 | InternKon: 201.18.07.10 / 04
|
|
|
|
|$$30 |
753 605
|
Cover, assy.
with fig-no: 28 |
1 |
InternBDB: 408 442 + 152 916
|
|
|
|
30 |
342 671 99
|
Circlip |
1 |
InternBDB: 105x4 /472 | InternKon: 201.18.07.10 / 12
|
|
|
|
|$$32 |
754 472
|
Repair kit
fig-nos: 07,26,28,29 |
-2 |
InternBDB: E-ST
|
|
|
|
|$$33 |
973 125
|
Fluid sealing to fig-no: 17 50 ml |
-2 |
InternBDB: Loctite 241
|
|
|
|
|$$34 |
989 946
|
Fluid sealing (pipe thread) 50 ml (Rohrgewinde) |
-2 |
InternBDB: Loctite 572
|
|
