PC4000-6E S/N 08202

Komatsu parts book diagram for PC4000-6E S/N 08202: SUCTION TANK

01 02 03 04 04 04 05 05 06 06 07 08 09 09 10 11 12 13 14 17 18 19 20 21

	#	Part Number	Partname	Quantity	Options	Reference
	01	945 932 40	Suction tank	1	InternKon: 945 931 40 / 1
	02	938 220 40	Tube	1	InternKon: 945 931 40 / 2
	03	941 103 40	Filter	1	InternBDB: NW200 HYDAC \| InternKon: 945 931 40 / 3
	04	396 093 40	Seal	3	InternBDB: SIL C-4400 340/205X2 \| InternKon: 945 931 40 / 4
	05	515 362 40	Oil drain valve	2	InternBDB: M26x1,5 \| InternKon: 945 931 40 / 5
	06	358 657 40	Plug	2	InternBDB: 1"NPT \| InternKon: 945 931 40 / 6
	07	173 495 40	Plug	1	InternBDB: Vsti M48x2,0 WN34191340 \| InternKon: 945 931 40 / 7
	08	504 134 98	Bolt	8	InternBDB: M20x85 8.8 DIN00933 \| InternKon: 945 931 40 / 8
	09	334 686 99	Nut	16	InternBDB: M 20 8 DIN00985 \| InternKon: 945 931 40 / 9
	10	270 048 40	Plug	1	InternBDB: Vsti R 1 1/4ED WN34191340 \| InternKon: 945 931 40 / 10
	11	324 550 40	Plug	1	InternBDB: 3/4" NPT \| InternKon: 945 931 40 / 11
	12	180 477 40	Plug	2	InternBDB: VSTI R1/2ED WN34191340 \| InternKon: 945 931 40 / 12
	13	938 221 40	Cover	1	InternKon: 945 931 40 / 13
	14	308 666 99	Bolt	8	InternBDB: M20x70 8.8 DIN00931 \| InternKon: 945 931 40 / 14
	17	501 924 98	Bolt	8	InternBDB: M20x110 10.9 DIN00931 \| InternKon: 94572140 / 7
	18	504 572 98	Nut	8	InternBDB: M20 DIN00934 \| InternKon: 94572140 / 8
	19	510 740 98	Resilient sleeve	8	InternBDB: 21/35x35 WN34194840 \| InternKon: 94572140 / 16
	20	308 667 99	Bolt	8	InternBDB: M20x75 8.8 DIN00931 \| InternKon: 945 725 40 / 42
	21	334 686 99	Nut	8	InternBDB: M20 DIN00985 8 \| InternKon: 945 725 40 / 43

Komatsu PC4000-6E S/N 08202 parts catalog PDF

SUCTION TANK (356-1804c) in PC4000-6E S/N 08202. Diagram image and parts list.
