OIL COOLER FAN DRIVE | PC4000-6E S/N 08202 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options	Reference
01		Fan motor	2	InternBDB: 358 677 40 \| InternKon: 937 570 40 / 11	090-1362
02	461 548 40	Fan	2	InternKon: 937 570 40 / 12
03	307 806 99	Bolt	8	InternBDB: M12x40 /933 \| InternKon: 937 570 40 / 21
04	307 869 99	Bolt	12	InternBDB: M12x35 /933 \| InternKon: 937 570 40 / 23
05	409 978 40	Locking plate	6	InternKon: 937 570 40 / 16
06	515 488 98	O-ring	2	InternBDB: 125,00x5,00 / NB70 \| InternKon: 937 570 40 / 17
07	500 128 98	Bolt	4	InternBDB: M24x220 / 931 \| InternKon: 937 570 40 / 24
08	316 213 99	Washer	4	InternBDB: 25 \| InternKon: 937 570 40 / 27
09	372 426 99	Union	2	InternBDB: CL 15 E / 2353 \| InternKon: 937 570 40 / 37
10	621 626 40	Sleeve	2	InternKon: 937 570 40 / 40
11	323 460 40	Bleeder	2	InternBDB: EV 1019 M22x1,5 \| InternKon: 937 570 40 / 41
14	895 907 40	Fan mounting	2	InternKon: 937 570 40 / 10
15	895 905 40	Bearing retainer	1	InternKon: 895 907 40 / 1
16	895 906 40	Shaft	1	InternKon: 895 907 40 / 2
17	342 555 99	Circlip	1	InternBDB: 60x2 /471 \| InternKon: 895 907 40 / 3
18	360 562 99	Roller bearing	2	InternBDB: 6212 RS /625 \| InternKon: 895 907 40 / 4
19	896 564 40	Shaft protecting sleeve	1	InternBDB: TS09 TS99315 80x24,0 \| InternKon: 895 907 40 / 5
20	907 463 40	Shaft seal	1	InternBDB: 80x120x13 \| InternKon: 895 907 40 / 6
21	173 493 40	Plug	1	InternBDB: VSTI M 18x1,5 \| InternKon: 895 907 40 / 7
22	914 439 40	Distance sleeve	1	InternKon: 895 907 40 / 8
\|$$21	792 965 73	Repair kit fig.-no. 06, 18 - 20	1
