01 |
938 996 40
|
Support, control unit, machined |
1 |
InternBDB: ab 08167, davor 88757040 unbearbeitet | InternKon: 938 580 40 / 1
|
|
|
|
02 |
887 574 40
|
Extension |
2 |
InternKon: 938 580 40 / 2
|
|
|
|
03 |
|
Control block |
1 |
InternBDB: 655 167 40 | InternKon: 938 520 40 / 66
|
991-0082 |
|
|
04 |
|
Control block |
1 |
InternBDB: 655 168 40 | InternKon: 938 580 40 / 4
|
991-0083 |
|
|
05 |
|
Control block |
1 |
InternBDB: 907 746 40 | InternKon: 938 580 40 / 5
|
991-0491 |
|
|
06 |
|
Control block |
1 |
InternBDB: 907 742 40 | InternKon: 938 580 40 / 6
|
991-0490 |
|
|
07 |
|
H.P. Filter |
4 |
InternBDB: 896 678 40 | InternKon: 938 580 40 / 7
|
991-0337a |
|
|
08 |
515 132 98
|
Bolt |
6 |
InternBDB: M16x250 /931 | InternKon: 938 580 40 / 12
|
|
|
|
09 |
308 313 99
|
Bolt |
6 |
InternBDB: M16x230 /931 | InternKon: 938 580 40 / 13
|
|
|
|
10 |
319 310 99
|
Bolt |
16 |
InternBDB: M20x50 /912 | InternKon: 938 580 40 / 14
|
|
|
|
11 |
319 287 99
|
Bolt |
16 |
InternBDB: M16x40 /912 | InternKon: 938 580 40 / 15
|
|
|
|
12 |
316 211 99
|
Washer |
12 |
InternBDB: 17 /6916 | InternKon: 938 580 40 / 18
|
|
|
|
13 |
514 904 98
|
Nut |
12 |
InternBDB: M 16 /985 | InternKon: 938 580 40 / 19
|
|
|
|
14 |
515 812 98
|
Coupling |
4 |
InternBDB: G1 /4-PC | InternKon: 938 580 40 / 20
|
|
|
|
15 |
356 209 40
|
Flange seal |
4 |
InternBDB: 1 1/2 NBR 90 | InternKon: 938 580 40 / 47
|
|
|
|
16 |
385 243 40
|
Flange seal |
10 |
InternBDB: 2 NBR 90 | InternKon: 938 580 40 / 48
|
|
|
|
17 |
901 862 40
|
Extension |
2 |
InternBDB: 113 | InternKon: 938 580 40 / 49
|
|
|
|
18 |
904 714 40
|
Plug with Test coupling connection 1/4" |
2 |
InternBDB: 2" | InternKon: 938 580 40 / 52
|
|
|
|
19 |
320 153 99
|
Bolt |
8 |
InternBDB: M 20x55 / 912 / 10.9 | InternKon: 938 580 40 / 53
|
|
|
|
20 |
937 327 40
|
Retainer assy. |
2 |
InternKon: 938 580 40 / 87
|
|
|
|
21 |
308 604 99
|
Bolt |
16 |
InternBDB: M12x50 / 8.8 DIN 931 | InternKon: 938 580 40 / 115
|
|
|
|
22 |
510 744 98
|
Resilent Sleeve |
16 |
InternBDB: 13/ 25x32 WN 34194840 | InternKon: 938 580 40 / 114
|
|
|
|
23 |
316 213 99
|
Washer |
4 |
InternBDB: 25 / 6916 | InternKon: 938 523 40 / 18
|
|
|
|
24 |
304 135 99
|
Bolt |
4 |
InternBDB: M 24x200 / 931 / 10.9 | InternKon: 938 523 40 / 16
|
|
|
|
26 |
937 325 40
|
Retainer assy. |
1 |
InternKon: 938 580 40 / 88
|
|
|
|
27 |
937 332 40
|
Retainer assy. |
1 |
InternKon: 938 580 40 / 89
|
|
|
|
28 |
931 477 40
|
Plug flange |
2 |
InternBDB: 2" | InternKon: 938 580 40 / 54
|
|
|
|
29 |
319 312 99
|
Bolt |
8 |
InternBDB: M20x65 /912 10.9 | InternKon: 938 580 40 / 55
|
|
