01 |
|
Gear pump unit |
1 |
InternBDB: 936 534 40 | InternKon: 947 701 40 / 45
|
991-0449b |
|
|
02 |
511 873 98
|
Bolt |
3 |
InternBDB: M10x50 A4-70 DIN00933 | InternKon: 947 701 40 / 119
|
|
|
|
03 |
515 220 98
|
Nut |
3 |
InternBDB: M10 A2-70 DIN00985 | InternKon: 947 701 40 / 120
|
|
|
|
04 |
516 849 98
|
Union |
1 |
InternBDB: T-L35 ISO8434 | InternKon: 947 701 40 / 106
|
|
|
|
07 |
511 136 40
|
Hose assy. |
1 |
InternBDB: NW25x810 DOL28 DOL28 WN34195140 | InternKon: 947 701 40 / 114
|
|
|
|
08 |
641 581 40
|
Retainer |
1 |
|
|
|
|
09 |
374 460 99
|
Socket |
7 |
InternBDB: L35R DIN03901 | InternKon: 947 701 40 / 97
|
|
|
|
10 |
516 162 98
|
Socket |
2 |
InternBDB: L35 DIN03942 | InternKon: 947 701 40 / 98
|
|
|
|
11 |
513 597 98
|
Hose assy. |
1 |
InternBDB: NW32x560 DOL35 DOL35 WN34195140 | InternKon: 947 701 40 / 115
|
|
|
|
12 |
516 473 98
|
Socket |
1 |
InternBDB: L35 DIN03944 | InternKon: 947 701 40 / 107
|
|
|
|
14 |
507 557 98
|
Union nut |
3 |
InternBDB: M45x2 DIN80705 | InternKon: 947 701 40 / 113
|
|
|
|
15 |
516 751 98
|
Union |
3 |
InternBDB: BH-L35 ISO8434 | InternKon: 947 701 40 / 112
|
|
|
|
16 |
516 188 98
|
Union |
3 |
InternBDB: L35G DIN03945 | InternKon: 947 701 40 / 109
|
|
|
|
17 |
516 753 98
|
Ball cock |
3 |
InternBDB: G1 1/4 MSNI | InternKon: 947 701 40 / 108
|
|
|
|
18 |
374 439 99
|
Socket |
1 |
InternBDB: SDS-L28xG1 A-TYPE E ISO08434 | InternKon: 947 701 40 / 123
|
|
|
|
22 |
518 504 98
|
Hose assy. DN32x4100 |
1 |
InternBDB: DOL35 /DOL35 | InternKon: 947 701 40 / 124
|
|
|
|
23 |
518 503 98
|
Hose assy. DN32x2400 |
2 |
InternBDB: DOL35 /DOL35 | InternKon: 947 701 40 / 116
|
|
|
|
26 |
506 308 98
|
Clamp set |
8 |
InternBDB: L-5-G-42 DIN03015 | InternKon: 947 701 40 / 117
|
|
|
|
27 |
319 418 99
|
Bolt |
16 |
InternBDB: M6x60 DIN00912 | InternKon: 947 701 40 / 118
|
|
|
|
28 |
576 471 40
|
Union |
1 |
InternBDB: RED35/28-PL/OMD | InternKon: 947 701 40 / 104
|
|
|
|
30 |
516 161 98
|
Socket |
1 |
InternBDB: SWE-L28 ST-NBR ISO08434-4 | InternKon: 947 701 40 / 105
|
|
|
|
31 |
516 189 98
|
Socket |
1 |
InternBDB: SWSDS-L28xM33x2 TYPE E ISO08434-4 | InternKon: 947 701 40 / 111
|
|
|
|
32 |
634 494 40
|
Union |
1 |
InternBDB: 35/28-L/OMD WN65593240 | InternKon: 947 701 40 / 96
|
|
|
|
33 |
534 008 99
|
Cover-plate |
1 |
InternBDB: S-DP-A-4W1 DIN03015 | InternKon: 947 701 40 / 184
|
|
|
|
34 |
506 371 98
|
Clamp set |
1 |
InternBDB: S-4-E PA DIN03015 | InternKon: 947 701 40 / 185
|
|
|
|
35 |
502 624 98
|
Gromet |
1 |
InternBDB: S-4-45,5 DIN03015 | InternKon: 947 701 40 / 186
|
|
|
|
36 |
319 162 99
|
Bolt |
2 |
InternBDB: M12x80 8.8 DIN00912 | InternKon: 947 701 40 / 187
|
|
|
|
37 |
340 508 99
|
Washer |
3 |
InternBDB: A10,5 STA2C DIN00125 | InternKon: 947 701 40 / 121
|
|
