OIL COOLER SYSTEM | PC4000-6 S/N 08195 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options
01	937 570 40	Oil cooler system assy.	1	InternKon: 937 515 40 / 10
02	502 082 98	Bolt (Standard)	4	InternBDB: M30x250 /931 \| InternKon: 937 515 40 / 14
03	513 028 98	Bolt (Cold weather design)	4	InternBDB: M30x250 /931
04	612 707 40	Resilient sleeve	4	InternBDB: 31 / 55x45 \| InternKon: 937 515 40 / 16
05	255 057 40	Washer	4	InternBDB: Ш 31 \| InternKon: 937 515 40 / 18
06	308 395 99	Bolt (Standard)	4	InternKon: 937 515 40 / 13
07	516 587 98	Bolt (Cold weather design)	4
08	902 082 40	Grid upper	1	InternKon: 937 570 40 / 14
09	511 885 98	Thread pin	18	InternBDB: PM 12 x 90 / 32500 \| InternKon: 937 570 40 / 34
10	895 969 40	Pipe	18	InternBDB: 21,3x4x65 \| InternKon: 937 570 40 / 36
11	334 600 99	Nut	58	InternBDB: M12 / 985 \| InternKon: 937 570 40 / 25
12	895 955 40	Radiator mounting assy. fig.-nos: 35-47	1	InternKon: 937 570 40 / 2
13	895 965 40	Radiator mounting assy. fig.-nos: 36-48	1	InternKon: 937 570 40 / 3
14	461 716 40	Profiled joint 12x12	-2	InternKon: 937 570 40 / 28
15	592 126 40	Profiled joint 15x30	-2	InternKon: 937 570 40 / 29
16	440 821 40	Profiled joint 30x30	-2	InternKon: 937 570 40 / 30
17	592 127 40	Profiled joint 15x15	-2	InternKon: 937 570 40 / 31
18	307 804 99	Bolt	24	InternBDB: M12x30 /933 \| InternKon: 937 570 40 / 22
19	341 337 99	Washer	48	InternBDB: 13,5 / 436 \| InternKon: 937 570 40 / 26
20	908 050 40	Fan Cage Top	1	InternKon: 937 570 40 / 6
21	942 230 40	Fan Cage Bottom	1	InternKon: 937 570 40 / 5
22	510 213 98	Thread pin	16	InternBDB: PM 12 x 30 / 32500 \| InternKon: 937 570 40 / 38
23	340 111 99	Washer	16	InternBDB: A14 \| InternKon: 937 570 40 / 39
24	515 487 98	Resilient sleeve	2	InternBDB: 25 / 45x42 \| InternKon: 937 570 40 / 20
25	316 213 99	Washer	6	InternBDB: 25 / 6916 \| InternKon: 937 570 40 / 27
26	506 755 98	Bolt	2	InternBDB: M24x460 \| InternKon: 937 570 40 / 18
27	504 193 98	Nut	2	InternBDB: M 24 / 985 / 10
28	390 641 40	Hinge assy.	6	InternKon: 937 570 40 / 8
29	574 527 40	Fan cowl	2	InternKon: 937 570 40 / 4
30	942 270 40	Frame	1	InternKon: 937 570 40 / 1
31	895 962 40	Oil cooler door	1	InternKon: 937 570 40 / 13
32	914 763 40	Grid lower	1	InternKon: 937 570 40 / 9
35	895 945 40	Radiator mounting w/o hinge	1	InternKon: 895 955 40 / 1
36	655 476 40	Oil cooler	4	InternBDB: AKG \| InternKon: 895 955 40 / 2
37	898 373 40	Angle	8	InternKon: 895 955 40 / 3
38	461 587 40	Buffer elements	8	InternKon: 895 955 40 / 4
39	480 169 40	Locking plate	16	InternKon: 895 955 40 / 5
40	308 640 99	Bolt	8	InternBDB: M16x120 /931 \| InternKon: 895 955 40 / 6
41	307 805 99	Bolt	32	InternBDB: M 12x35 / 933 \| InternKon: 895 955 40 / 7
42	308 575 99	Bolt	32	InternBDB: M10x40 /931 \| InternKon: 895 955 40 / 8
43	334 601 99	Nut	8	InternBDB: M16 / 985 \| InternKon: 895 955 40 / 9
44	507 037 98	Nut	32	InternBDB: M10 / 985 \| InternKon: 895 955 40 / 10
45	316 211 99	Washer	8	InternBDB: 17 / 6916 \| InternKon: 895 955 40 / 11
46	340 467 99	Washer	32	InternBDB: 13,0 / 125 \| InternKon: 895 955 40 / 12
47	340 465 99	Washer	64	InternBDB: B 10,5 / 125 \| InternKon: 895 955 40 / 13
48	895 960 40	Radiator mounting w/o hinge	1	InternKon: 895 965 40 / 1
52	621 107 40	Pin	1	InternKon: 390 641 40 / 1
53	390 642 40	Round bar steel	2	InternKon: 390 641 40 / 2
54	390 643 40	Round bar steel	1	InternKon: 390 641 40 / 3
55	340 619 99	Washer	1	InternBDB: 30 / 1440 \| InternKon: 390 641 40 / 4
56	342 121 99	Cotter pin	1	InternBDB: 8x50 \| InternKon: 390 641 40 / 5
57	350 562 99	Grease nipple	1	InternBDB: AM 10x1 \| InternKon: 390 641 40 / 6
58	942 260 40	Fan Cage Bottom	1	InternKon: 937 570 40 / 42
