VALVE CONTROL BLOCK (BE) | PC4000-6 S/N 08195 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

PC4000-6 S/N 08195

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Options	Reference
?		Pressure valve	7	InternBDB: 356 198 40 MO 7090 MH1DBV32-P2-1X/420YM \| InternKon: 938 580 40 / 10	090-0359
?		Anticavitation valve	4	InternBDB: 256 164 40 307121 MHSV 22 ZB1-1X/M MO 7151 \| InternKon: 938 580 40 / 11	090-0226
?	319 261 99	Bolt	44	InternBDB: M10x60 / DIN 912 \| InternKon: 938 580 40 / 16
?	516 183 98	Socket	2	InternBDB: L10-G / ST-NBR / DIN 03945 \| InternKon: 938 525 40 / 17
?	373 764 99	Union	2	InternBDB: TR 15/10/10PL / ST ZN / WN 01087799 \| InternKon: 938 525 40 / 20
?	516 175 98	Swivel run tee	1	InternBDB: SWRT-L 15 / ST-NBR / ISO 08434-4 \| InternKon: 938 525 40 / 21
?	516 306 98	Hose assy. DN 8 x 230	1	InternBDB: 050 / DOL 10 / DOL 10 / WN 34195140 \| InternKon: 938 525 40 / 22
?	443 451 210	Clip	7	InternBDB: DN 12 / 77 / KES 04434 \| InternKon: 938 525 40 / 26
?	307 775 99	Bolt	5	InternBDB: M10x20 / 8.8 / DIN 933 \| InternKon: 938 525 40 / 27
?	507 037 98	Nut	5	InternBDB: M10 / 8 / DIN 985 \| InternKon: 938 525 40 / 28
?	340 465 99	Washer	5	InternBDB: B 10,5 / 140HV / DIN 125 \| InternKon: 938 525 40 / 29
?	906 806 40	Union	6	InternBDB: TH10-LR KDS / ST A3C / \| InternKon: 938 525 40 / 30
?	006 894 98	Union	1	InternBDB: VOSS 10-LR / ST ZN / WN 01175499 \| InternKon: 938 525 40 / 31
?	516 318 98	Hose assy. DN 8 x 980	1	InternBDB: 050 / DOL 10 / DOL 10 90 / WN 34195140 \| InternKon: 938 525 40 / 32
?	518 093 98	Hose assy. DN 8 x 1200	1	InternBDB: 050 / DOL 10 / DOL 10 / WN 34195140 \| InternKon: 938 525 40 / 33
?	516 313 98	Hose assy. DN 8 x 930	1	InternBDB: 050 / DOL 10 / DOL 10 90 / WN 34195140 \| InternKon: 938 525 40 / 34
?	516 308 98	Hose assy. DN 8 x 400	2	InternBDB: DN 8 x 400 / DOL 10 / DOL 10 90 / WN 34195140 \| InternKon: 938 525 40 / 43
?	516 317 98	Hose assy. DN 8 x 500	1	InternBDB: 050 / DOL 10 / DOL 10 90 / WN 34195140 \| InternKon: 938 525 40 / 47
?	516 536 98	Hose assy. DN 12 x 3900	1	InternBDB: 240 DOL 15 /DOL 15-90 \| InternKon: 938 200 40 / 32
?	374 407 99	Socket	1	InternBDB: SDS-L15xM18x1,5 - Type E / ISO 8434 / St A3C \| InternKon: 938 200 40 / 47
