01 |
756 416 73
|
Bleed-off valve, mutual, assy. |
1 |
InternBDB: Rexroth MH 2DB VV 22 BP 9-1x /420 YM 405 195 AT-Nr. 669 301
|
|
|
|
02 |
|
Pressure sequence stage |
2 |
InternBDB: 134 245 | InternKon: 90-0453 / 2
|
090-0182 |
|
|
03 |
753 717
|
Pin |
2 |
InternBDB: 169264 | InternKon: 90-0453 / 5
|
|
|
|
04 |
994 280
|
Compression spring |
2 |
InternBDB: 008721 | InternKon: 90-0453 / 14
|
|
|
|
05 |
753 718
|
Taper |
2 |
InternBDB: 104357 | InternKon: 90-0453 / 3
|
|
|
|
06 |
753 719
|
Valve seat |
2 |
InternBDB: 169263 | InternKon: 90-0453 / 4
|
|
|
|
07 |
000 165 98
|
O-ring |
2 |
InternBDB: 30x3 | InternKon: 90-0453 / 16
|
|
|
|
08 |
994 331
|
Compression spring |
2 |
InternBDB: 006774 | InternKon: 90-0453 / 15
|
|
|
|
09 |
756 555 73
|
Piston |
2 |
InternBDB: 134245 | InternKon: 90-0453 / 2
|
|
|
|
10 |
000 157 98
|
O-ring |
4 |
InternBDB: 18x2,5 | InternKon: 90-0453 / 13
|
|
|
|
11 |
368 097 40
|
Ring |
4 |
InternBDB: AG 7041 | InternKon: 90-0453 / 26
|
|
|
|
12 |
994 816
|
Screw plug |
1 |
InternBDB: 147773 | InternKon: 90-0453 / 7
|
|
|
|
13 |
501 275 98
|
O-ring |
1 |
InternBDB: 29x3 | InternKon: 90-0453 / 11
|
|
|
|
14 |
994 130
|
Screw plug |
23 |
InternBDB: 148441 | InternKon: 90-0453 / 23
|
|
|
|
15 |
990 756
|
O-ring |
2 |
InternBDB: 18,72x2,62 | InternKon: 90-0453 / 24
|
|
|
|
16 |
|
Piston
These parts are not sold
separately |
1 |
InternKon: 90-0453 / 10
|
|
|
|
17 |
994 820
|
Spring plate |
1 |
InternBDB: 147775 | InternKon: 90-0453 / 19
|
|
|
|
18 |
994 819
|
Compression spring |
1 |
InternBDB: 009447 | InternKon: 90-0453 / 21
|
|
|
|
19 |
972 073
|
O-ring |
1 |
InternBDB: 40,94x2,62 | InternKon: 90-0453 / 22
|
|
|
|
20 |
994 818
|
Cover |
1 |
InternBDB: 147769 | InternKon: 90-0453 / 6
|
|
|
|
21 |
319 539 99
|
Screw |
2 |
InternBDB: M6x16/912 | InternKon: 90-0453 / 20
|
|
|
|
|$$22 |
691 032
|
Seal kit
fig-nos: 07,10,11,13,15,19 |
1 |
InternBDB: 309647
|
|
