|$$1 |
|
Graphic 1 |
-1 |
|
|
|
|
01 |
368 070 40
|
Load limitation valve assy.
for H 121 (all diesel engines) |
1 |
InternBDB: BrÑŒnighaus
|
|
|
|
01 |
414 087 40
|
Load limitation valve assy.
for H 65 / H 135 |
1 |
InternBDB: 802 674
|
|
|
|
02 |
753 977
|
Connection block |
1 |
InternBDB: 586 714 | InternKon: 144-1886b / 04
|
|
|
|
03 |
756 217 73
|
Cartridge assy. for H 121
consist. of fig-nos: 07-22 |
1 |
InternBDB: 800 479 Blende 6,2 AT-Nr. 669 206 73 | InternKon: 144-1886b / 01
|
|
|
|
03 |
756 218 73
|
Cartridge assy.
for H 65 / H 135
consist. of fig-nos: 07-22 |
1 |
InternBDB: 802 673 Blende 5,6 | InternKon: 144-1886b / 01
|
|
|
|
04 |
994 402
|
Pressure relief valve assy. consist. of fig-nos: 30-40 30 bar best. aus |
1 |
InternBDB: 570 206 | InternKon: 144-1886b / 02
|
|
|
|
05 |
998 592
|
Plug |
1 |
InternBDB: vsti 16x1,5 ed /sa-1 | InternKon: 144-1886b / 06
|
|
|
|
06 |
171 260 40
|
Plug |
3 |
InternBDB: vsti 12x1,5- ed | InternKon: 144-1886b / 07
|
|
|
|
|$$10 |
|
Graphic 2 |
-1 |
|
|
|
|
07 |
|
Thread pin |
1 |
InternBDB: M6x55 /913 154 968 | InternKon: 144-1886b / 22
|
|
|
|
08 |
964 663
|
Nut |
1 |
InternBDB: M6 152 425 | InternKon: 144-1886b / 21
|
|
|
|
09 |
333 212 99
|
Nut |
1 |
InternBDB: M12x1,5 /936 | InternKon: 144-1886b / 20
|
|
|
|
10 |
753 979
|
Adjusting screw |
1 |
InternBDB: 571 938 | InternKon: 144-1886b / 01
|
|
|
|
11 |
500 383 98
|
O-ring |
1 |
InternBDB: 31,42x2,62 | InternKon: 144-1886b / 15
|
|
|
|
12 |
500 287 98
|
O-ring |
1 |
InternBDB: 9,25x1,78 | InternKon: 144-1886b / 13
|
|
|
|
13 |
753 980
|
Thread bush |
1 |
InternBDB: 071 532 | InternKon: 144-1886b / 12
|
|
|
|
14 |
753 981
|
Spring plate |
1 |
InternBDB: 572 179 | InternKon: 144-1886b / 05
|
|
|
|
15 |
994 401
|
Spring |
1 |
InternBDB: 572 187 | InternKon: 144-1886b / 08
|
|
|
|
16 |
753 982
|
Spring plate |
1 |
InternBDB: 572 152 | InternKon: 144-1886b / 11
|
|
|
|
17 |
973 334 73
|
Snap ring |
1 |
InternBDB: Seeger V-Ring A17x1 | InternKon: 144-1886b / 23
|
|
|
|
18 |
753 983
|
Ring |
1 |
InternBDB: 571 628 | InternKon: 144-1886b / 06
|
|
|
|
19 |
|
Differential piston (H 121) |
1 |
InternKon: 144-1886b / 02
|
|
|
|
19 |
756 219 73
|
Differential piston (H 65 / H 135) |
1 |
InternBDB: 572 144 | InternKon: 144-1886b / 02
|
|
|
|
20 |
753 985
|
Governor tube |
1 |
InternBDB: 571 946 | InternKon: 144-1886b / 03
|
|
|
|
21 |
754 895 73
|
Disk |
1 |
InternBDB: 833 983 | InternKon: 144-1886b / 28
|
|
|
|
22 |
|
Spring |
1 |
InternBDB: 074 386 | InternKon: 144-1886b / 25
|
|
|
|
|$$28 |
|
Graphic 3 |
-1 |
|
|
|
|
30 |
964 663
|
Nut |
1 |
InternBDB: M6 152 425 | InternKon: 144-1886b / 10
|
|
|
|
31 |
753 987
|
Adapter sleeve |
1 |
InternBDB: 572 063 | InternKon: 144-1886b / 03
|
|
|
|
32 |
753 986
|
Adjusting screw |
1 |
InternBDB: 570 192 | InternKon: 144-1886b / 01
|
|
|
|
33 |
972 044
|
O-ring |
1 |
InternBDB: 21,82x3,53 | InternKon: 144-1886b / 14
|
|
|
|
34 |
753 988
|
Disk |
1 |
InternBDB: 570 931 | InternKon: 144-1886b / 04
|
|
|
|
35 |
753 989
|
Screw |
1 |
InternBDB: 571 229 | InternKon: 144-1886b / 06
|
|
|
|
36 |
994 403
|
Spring |
1 |
InternBDB: 571 997 | InternKon: 144-1886b / 07
|
|
|
|
37 |
753 990
|
Valve taper |
1 |
InternBDB: 571 644 | InternKon: 144-1886b / 05
|
|
|
|
38 |
753 991
|
Valve bush |
1 |
InternBDB: 572 829 | InternKon: 144-1886b / 02
|
|
|
|
39 |
500 383 98
|
O-ring |
1 |
InternBDB: 31,42x2,62 | InternKon: 144-1886b / 12
|
|
|
|
40 |
500 302 98
|
O-ring |
1 |
InternBDB: 23,47x2,62 | InternKon: 144-1886b / 11
|
|
|
|
|$$40 |
753 976
|
Seal kit assy.
consist. of fig-nos: 05,06,08,
11,12,30,33,39,40 |
-2 |
InternBDB: E-ST
|
|
