01 |
427 118 40
|
Distributor block |
1 |
InternKon: 427 120 40 / 2
|
|
|
|
02 |
420 142 40
|
Valve plate |
2 |
InternKon: 427 120 40 / 3
|
|
|
|
03 |
427 273 40
|
Valve plate |
1 |
InternKon: 427 120 40 / 4
|
|
|
|
04 |
420 144 40
|
Valve plate |
1 |
InternKon: 427 120 40 / 5
|
|
|
|
05 |
420 145 40
|
Valve cover |
13 |
InternKon: 427 120 40 / 6
|
|
|
|
06 |
343 252 40
|
Dummy flange |
1 |
InternBDB: 1/2"-3000 Psi | InternKon: 427 120 40 / 7
|
|
|
|
07 |
504 600 98
|
O-ring |
8 |
InternBDB: 32,9x3,5NB90 | InternKon: 427 120 40 / 23
|
|
|
|
08 |
414 217 40
|
2-Directional spool valve |
13 |
InternBDB: Rexroth LC25BO5E 6x/B40 | InternKon: 427 120 40 / 31
|
|
|
|
09 |
414 251 40
|
Pressure relief valve |
2 |
InternBDB: MHDB-40K2-1x/ 420YM 307 942 | InternKon: 427 120 40 / 32
|
|
|
|
10 |
319 269 99
|
Bolt |
60 |
InternBDB: M12x45/912 | InternKon: 427 120 40 / 36
|
|
|
|
11 |
319 281 99
|
Bolt |
4 |
InternBDB: M12x110/912 | InternKon: 427 120 40 / 35
|
|
|
|
12 |
500 250 98
|
Bolt |
8 |
InternBDB: M12x155/912 | InternKon: 427 120 40 / 34
|
|
|
|
13 |
153 646 40
|
Test coupling |
1 |
InternBDB: AR 1/4 ST2103-01- 51.00 | InternKon: 427 120 40 / 41
|
|
|
|
14 |
427 116 40
|
Valve plate |
1 |
InternKon: 427 120 40 / 44
|
|
|
|
15 |
180 113 40
|
Plug |
1 |
InternBDB: vsti G 1/4 ed | InternKon: 427 120 40 / 43
|
|
|
|
16 |
173 494 40
|
Plug |
3 |
InternBDB: vsti M33x2 ed | InternKon: 427 120 40 / 24
|
|
|
|
17 |
427 229 40
|
Valve cover |
1 |
InternKon: 427 120 40 / 49
|
|
|
|
18 |
504 904 98
|
Bolt |
4 |
InternBDB: M12x180 /912 | InternKon: 427 120 40 / 46
|
|
|
|
|$$19 |
697 905 73
|
Seal kit to fig-no: 08 |
-2 |
InternBDB: Rexroth 314 354
|
|
|
|
|$$20 |
994 304
|
Seal kit to fig-no: 09 |
-2 |
InternBDB: 309 657
|
|
