697 062 73
|
Pipe assy. Ш 38 |
2 |
InternBDB: 427 076 40 | InternKon: 420 170 40 / 14
|
|
|
|
? |
414 632 40
|
Hose assy. NW 32x1520 |
1 |
InternBDB: Typ GH 506 SFL-6-1 1/4" /SFL-6-45- 1 1/4" | InternKon: 420 170 40 / 2
|
|
|
|
? |
414 634 40
|
Hose assy. NW 32x1930 |
1 |
InternBDB: Typ GH 506 SFL-6-1 1/4" /SFL-6-90- 1 1/4" | InternKon: 420 170 40 / 4
|
|
|
|
? |
414 536 40
|
Hose assy. NW 32x2650 |
1 |
InternBDB: Typ GH 506 SFL-6-1 1/4" /SFL-6-90- 1 1/4" | InternKon: 420 170 40 / 3
|
|
|
|
? |
145 826 40
|
Half flange |
6 |
InternBDB: 32 /420 | InternKon: 420 170 40 / 140
|
|
|
|
? |
006 725 98
|
O-ring |
9 |
InternBDB: 37,69x3,53 | InternKon: 420 170 40 / 141
|
|
|
|
? |
319 209 99
|
Bolt |
24 |
InternBDB: M14x45 /912 | InternKon: 420 170 40 / 142
|
|
|
|
? |
500 129 98
|
Flange |
6 |
InternBDB: FE-3800-20/6 | InternKon: 420 170 40 / 137
|
|
|
|
? |
501 871 98
|
Collar ring |
3 |
InternBDB: K-3850-20 | InternKon: 420 170 40 / 138
|
|
|
|
? |
500 202 98
|
Collar ring |
3 |
InternBDB: KO-3850-20 | InternKon: 420 170 40 / 139
|
|
|
|
? |
319 486 99
|
Bolt |
12 |
InternBDB: M14x70 /912 | InternKon: 420 170 40 / 143
|
|
|
|
? |
502 371 98
|
Half clamp |
6 |
InternBDB: RI-CS 6 | InternKon: 420 170 40 / 124
|
|
|
|
? |
502 624 98
|
Insert |
3 |
InternBDB: RI-Z 45,5 | InternKon: 420 170 40 / 132
|
|
|
|
? |
534 008 99
|
Plate |
2 |
InternBDB: DS 6 | InternKon: 420 170 40 / 118
|
|
|
|
? |
427 079 40
|
Threaded rod |
2 |
InternBDB: M12x320 /975 | InternKon: 420 170 40 / 128
|
|
|
|
? |
332 334 99
|
Nut |
4 |
InternBDB: M 12 /934 | InternKon: 420 170 40 / 129
|
|
|
|
? |
332 226 99
|
Nut |
12 |
InternBDB: M 14 /934 | InternKon: 420 170 40 / 144
|
|
|
|
? |
697 061 73
|
Pipe assy. Ш 38 |
1 |
InternBDB: 427 075 40 | InternKon: 420 170 40 / 13
|
|
