01 |
414 640 40
|
Hose assy. NW 25x3700 lg. |
2 |
InternBDB: GH506-16x3700 SFL-6-1"/SFL-6-1" | InternKon: 420 170 40 / 10
|
|
|
|
02 |
|
Bullclam bucket equipment
s.p. 65-1840c fig-no: 25
Backhoe equipment
s.p. 65-1847 fig-no:16 |
2 |
InternBDB: GH506-16x4500 SFL-6-1"/SFL-6-90-1" | InternKon: 420 170 40 / 11
|
|
|
|
04 |
414 656 40
|
Hose assy. NW 40x2500 lg. |
2 |
InternBDB: GH506-24x2500 SFL-6-1 1/4" SFL-6-1 1/2" | InternKon: 420 170 40 / 12
|
|
|
|
05 |
006 637 98
|
Half flange |
6 |
InternBDB: 25 /420 | InternKon: 420 170 40 / 153
|
|
|
|
06 |
006 720 98
|
O-ring |
6 |
InternBDB: 33x3,5 | InternKon: 420 170 40 / 154
|
|
|
|
07 |
319 274 99
|
Bolt |
24 |
InternBDB: M12x40 /912 | InternKon: 420 170 40 / 155
|
|
|
|
08 |
006 638 98
|
Half flange |
2 |
InternBDB: 32 /420 | InternKon: 420 170 40 / 140
|
|
|
|
09 |
006 725 98
|
O-ring |
2 |
InternBDB: 37,69x3,53 | InternKon: 420 170 40 / 141
|
|
|
|
10 |
319 486 99
|
Bolt |
8 |
InternBDB: M14x45 /912 | InternKon: 420 170 40 / 142
|
|
|
|
11 |
332 334 99
|
Nut |
8 |
InternBDB: M 12 /934 | InternKon: 420 170 40 / 129
|
|
|
|
12 |
427 078 40
|
Threaded rod |
2 |
InternBDB: M12x1000/975 | InternKon: 420 170 40 / 127
|
|
|
|
13 |
534 008 99
|
Plate |
2 |
InternBDB: DS 6 | InternKon: 420 170 40 / 118
|
|
|
|
14 |
502 371 98
|
Clamp |
20 |
InternBDB: RI-CS 6 | InternKon: 420 170 40 / 124
|
|
|
|
15 |
502 831 98
|
Insert |
8 |
InternBDB: RI-Z 38 | InternKon: 420 170 40 / 130
|
|
|
|
16 |
505 729 98
|
Insert |
2 |
InternBDB: RI-Z 53,4 | InternKon: 420 170 40 / 131
|
|
|
|
17 |
436 989 40
|
Hose clamp assy. |
1 |
|
|
|
|
18 |
436 985 40
|
Hose clamp |
1 |
InternKon: 436 989 40 / 1
|
|
|
|
19 |
308 584 99
|
Bolt |
12 |
InternBDB: M10x90 /931 | InternKon: 436 989 40 / 4
|
|
|
|
20 |
504 827 98
|
Clamp |
12 |
InternBDB: H-CS5 /38 | InternKon: 436 989 40 / 2
|
|
|
|
21 |
534 004 99
|
Plate |
6 |
InternBDB: DS 5 | InternKon: 436 989 40 / 3
|
|
|
|
22 |
332 113 99
|
Nut |
24 |
InternBDB: M10 /934 | InternKon: 436 989 40 / 5
|
|
