PC3000-6E S/N 06262

Komatsu parts book diagram for PC3000-6E S/N 06262: VALVE BLOCK

? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	918 375 40	Valve block fig-nos: 02-04	1	InternBDB: DBM
	?	399 216 40	Valve block	1	InternKon: 918 375 40 / 1
	?	576 338 40	Valve - mounting kit fig-nos: 05-16	1	InternBDB: Rexroth L-DBF 50-2-30 /16 Y-SO 586 /522 883 \| InternKon: 918 375 40 / 2
	?	319 277 99	Screw	4	InternBDB: M12x70 /912
	?	255 694 40	Screw plug	2	InternBDB: Rexroth G 3/8 002 423
	?	313 500 99	Eyebolt	2	InternBDB: M 8 /580
	?		Bush	1	InternBDB: Rexroth 173 825
	?	693 471	Piston	1	InternBDB: Rexroth 173 815
	?	693 475	Compression spring	1	InternBDB: Rexroth 009 184
	?	950 035	O-ring	1	InternBDB: 76x3 004 482
	?	693 476	Pressure relief valve	1	InternBDB: Rexroth DBDS 10 K 10/ 25 SO.52 /488 053
	?	313 404 99	Plug	1	InternBDB: M8x1 /906 003 443

Komatsu PC3000-6E S/N 06262 parts catalog PDF

VALVE BLOCK (612-1837) in PC3000-6E S/N 06262. Diagram image and parts list.
