01 |
936 534 40
|
Gear pump unit |
1 |
InternBDB: TL / Fa. Kracht KF40/RF1 PUAG 3731
|
|
|
|
02 |
793 818 73
|
D.C.-motor |
1 |
InternBDB: 0,7kw DC 24V 1500 U/min. EMP /Claret APP80
|
|
|
|
03 |
792 743 73
|
Carrier, pump |
1 |
InternBDB: PT 200-A-080-100 W.5016005502
|
|
|
|
04 |
792 744 73
|
Coupling |
1 |
InternBDB: RA 19/24-Z25/24-Z25/19 NV W.0012200575
|
|
|
|
05 |
792 745 73
|
Gear pump |
1 |
InternBDB: KF 40 RF1 31127972 P.0127970002
|
|
|
|
06 |
792 746 73
|
Threaded flange |
2 |
InternBDB: G - SAE 1 1 1/2 N SAE 1 1/2 - G 1 1/4 -3000 PSI - Perb. L.003605
|
|
|
|
07 |
792 747 73
|
Housing |
1 |
InternBDB: E.018992001 KF 40 | InternKon: 31127972 / 10
|
|
|
|
08 |
792 748 73
|
Drive gear |
1 |
InternBDB: E.0189130001 KF 40 | InternKon: 31127972 / 20
|
|
|
|
09 |
792 749 73
|
Gear |
1 |
InternBDB: E.0189180001 KF 40 | InternKon: 31127972 / 30
|
|
|
|
10 |
792 750 73
|
Bearing bush |
4 |
InternBDB: E.0004270001 KF 4 40/420
|
|
|
|
11 |
354 274 99
|
Feather key |
2 |
InternBDB: A8x7x28 | InternKon: 31127972 / 60
|
|
|
|
12 |
307 779 99
|
Bolt |
4 |
InternBDB: M10x30 /933 8.8 | InternKon: 31127972 / 70
|
|
|
|
13 |
517 279 98
|
Dowel sleeve |
2 |
InternBDB: 8x24 | InternKon: 31127972 / 80
|
|
|
|
14 |
517 278 98
|
O-ring |
1 |
InternBDB: 88,57x2,62 NB 90 | InternKon: 31127972 / 200
|
|
|
|
15 |
517 280 98
|
Shaft seal |
1 |
InternBDB: 25x42x6 NB 90 | InternKon: 31127972 / 210
|
|
|
|
16 |
342 642 99
|
Circlip |
1 |
InternBDB: 42x1,75 | InternKon: 31127972 / 220
|
|
|
|
17 |
792 751 73
|
Protective plug |
2 |
InternBDB: L 0064000069 | InternKon: 31127972 / 320
|
|
|
|
18 |
792 752 73
|
Cover |
1 |
InternBDB: E 0189900001 KF 32-80 | InternKon: 31127972 / 410
|
|
