01 |
655 168 40
|
Control block |
1 |
InternBDB: Rexroth MO-3455-00/4 MO-40 Nr. 919 635 AT-Nr. 710 695 73
|
|
|
|
02 |
|
Housing |
1 |
InternBDB: 160 179 | InternKon: 485-1850 / 1
|
|
|
|
03 |
319 429 99
|
Bolt |
32 |
InternBDB: M10x20/912 | InternKon: 485-1850 / 60
|
|
|
|
04 |
767 743 73
|
Cover |
4 |
InternBDB: 859 615 | InternKon: 485-1850 / 14
|
|
|
|
05 |
994 477
|
Pin |
4 |
InternBDB: 149 908 | InternKon: 485-1850 / 10
|
|
|
|
06 |
994 476
|
Spring plate |
8 |
InternBDB: 152 040 | InternKon: 485-1850 / 11
|
|
|
|
07 |
994 473
|
Spring |
4 |
InternBDB: 001 599 | InternKon: 485-1850 / 13
|
|
|
|
08 |
994 472
|
Spring |
4 |
InternBDB: 001 600 | InternKon: 485-1850 / 12
|
|
|
|
09 |
500 581 98
|
O-ring |
8 |
InternBDB: 82,14x3,53 | InternKon: 485-1850 / 16
|
|
|
|
10 |
767 746 73
|
Piston assy. |
1 |
InternBDB: 859 622 | InternKon: 485-1850 / 3
|
|
|
|
11 |
767 745 73
|
Piston assy. |
3 |
InternBDB: 859 653 | InternKon: 485-1850 / 2
|
|
|
|
12 |
994 484
|
Seal kit for piston axle |
4 |
InternBDB: 309 648 | InternKon: 485-1850 / 800
|
|
|
|
13 |
754 581
|
Cover |
4 |
InternBDB: 684 393 | InternKon: 485-1850 / 15
|
|
|
|
14 |
319 256 99
|
Bolt |
16 |
InternBDB: M10x25/912 | InternKon: 485-1850 / 19
|
|
|
|
15 |
763 273 73
|
Plug |
1 |
InternBDB: 023 945 | InternKon: 485-1850 / 26
|
|
|
|
16 |
500 582 98
|
O-ring |
1 |
InternBDB: 82,14x3,53
|
|
|
|
17 |
313 503 99
|
Eye bolt |
2 |
InternBDB: M16/580 | InternKon: 485-1850 / 16
|
|
|
|
18 |
508 728 98
|
Washer |
2 |
InternBDB: Ш 21 /125 | InternKon: 485-1850 / 58
|
|
|
|
19 |
994 471
|
Plug |
4 |
InternBDB: 147 997 | InternKon: 485-1850 / 20
|
|
|
|
20 |
255 012 40
|
Spring |
4 |
InternBDB: 008 862 | InternKon: 485-1850 / 22
|
|
|
|
21 |
255 011 40
|
Taper |
4 |
InternBDB: 147 996 | InternKon: 485-1850 / 21
|
|
|
|
22 |
288 761 40
|
O-ring |
4 |
InternBDB: 44x3 | InternKon: 485-1850 / 23
|
|
|
|
23 |
|
Pressure relief valve |
1 |
InternBDB: 324 590 40 | InternKon: 485-1850 / 50
|
090-0186 |
|
|
24 |
994 410
|
Plate |
8 |
InternBDB: 303 897 | InternKon: 485-1850 / 54
|
|
|
|
25 |
994 376
|
Seal kit to fig-no.: 24 |
8 |
InternBDB: 309 641
|
|
|
|
26 |
767 747 73
|
Pin |
1 |
InternBDB: 859 656 | InternKon: 485-1850 / 9
|
|
