01 |
929 497 40
|
Rotary joint, assy. |
1 |
InternKon: 919 850 40 / 1
|
|
|
|
02 |
319 299 99
|
Screw |
4 |
InternBDB: M16 x 70 /912 10.9 | InternKon: 911 333 40 / 27
|
|
|
|
03 |
917 889 40
|
Cover |
1 |
InternKon: 911 333 40 / 5
|
|
|
|
04 |
360 924 40
|
Sealing element |
9 |
InternBDB: Bu. u. Luy. GS-50993- 3202-10N | InternKon: 911 333 40 / 12
|
|
|
|
05 |
515 358 98
|
O-ring |
9 |
InternBDB: Bu. u. Luy. 278,8x7 451-MS-28775 | InternKon: 911 333 40 / 13
|
|
|
|
06 |
304 357 99
|
Bolt |
8 |
InternBDB: M16 x 160 /931 10.9 | InternKon: 911 333 40 / 26
|
|
|
|
07 |
316 211 99
|
Washer |
8 |
InternBDB: 17 /6916 | InternKon: 911 333 40 / 29
|
|
|
|
08 |
917 886 40
|
Driving ring |
1 |
InternKon: 911 333 40 / 3
|
|
|
|
09 |
004 860 98
|
Grease nipple |
2 |
InternBDB: AR 1/4 011 207 99 | InternKon: 911 333 40 / 31
|
|
|
|
10 |
365 405 40
|
Race |
1 |
InternKon: 911 333 40 / 6
|
|
|
|
11 |
502 860 98
|
O-ring |
1 |
InternBDB: 190 x 10 /70 3770 | InternKon: 911 333 40 / 20
|
|
|
|
12 |
911 331 40
|
Rotor |
1 |
InternKon: 911 333 40 / 1
|
|
|
|
14 |
517 860 98
|
O-ring |
4 |
InternBDB: 47,5x4 /80 3770 | InternKon: 911 333 40 / 21
|
|
|
|
15 |
360 932 40
|
Support ring |
4 |
InternBDB: Prдdifa 1,5x48,2x55 | InternKon: 911 333 40 / 22
|
|
|
|
16 |
507 718 40
|
Plug |
4 |
InternKon: 911 333 40 / 8
|
|
|
|
17 |
365 411 40
|
Plug |
4 |
InternKon: 911 333 40 / 9
|
|
|
|
18 |
655 533 40
|
Piston guide ring |
2 |
InternBDB: Bu. u. Luy. GP-75-03000-c380 | InternKon: 911 333 40 / 14
|
|
|
|
19 |
504 376 98
|
O-ring |
1 |
InternBDB: 335 x 10 /70 3770 | InternKon: 911 333 40 / 19
|
|
|
|
20 |
911 332 40
|
Housing |
1 |
InternKon: 911 333 40 / 2
|
|
|
|
21 |
365 408 40
|
Half disk |
2 |
InternKon: 911 333 40 / 10
|
|
|
|
22 |
929 481 40
|
Centering disk |
1 |
InternKon: 911 333 40 / 11
|
|
|
|
23 |
517 121 98
|
Washer |
8 |
InternBDB: 8 WN 65593840 | InternKon: 911 333 40 / 30
|
|
|
|
24 |
307 754 99
|
Bolt |
8 |
InternBDB: M8 x 25 /933 | InternKon: 911 333 40 / 28
|
|
|
|
28 |
173 493 40
|
Plug |
3 |
InternBDB: Vsti M18 x 1,5 ed | InternKon: 911 333 40 / 24
|
|
|
|
29 |
168 474 40
|
Plug |
1 |
InternBDB: Vsti M42 x 2- ed | InternKon: 911 333 40 / 23
|
|
|
|
30 |
430 607 40
|
Support flange |
1 |
InternKon: 911 333 40 / 7
|
|
|
|
31 |
342 595 99
|
Ring |
1 |
InternBDB: 250 x 5 / 471 | InternKon: 911 333 40 / 25
|
|
|
|
32 |
917 887 40
|
Clam ring |
1 |
InternKon: 911 333 40 / 4
|
|
|
|
33 |
907 055 40
|
Seal ring |
1 |
InternBDB: TG 34-02800-T40 | InternKon: 911 333 40 / 15
|
|
|
|
34 |
515 788 98
|
O-ring |
1 |
InternBDB: 291,47x7,00 B 7237 | InternKon: 911 333 40 / 16
|
|
|
|
35 |
907 053 40
|
Seal ring |
1 |
InternBDB: TVM 0 2800-T40S | InternKon: 911 333 40 / 17
|
|
|
|
36 |
907 054 40
|
Seal ring |
1 |
InternBDB: VL 285-305 TWVL 03000-N60 | InternKon: 911 333 40 / 18
|
|
|
|
|$$33 |
770 555 73
|
Seal kit fig-nos. 04,05,11,14,15,18,19.33-36 |
-2 |
InternBDB: E-ST
|
|
