01 |
795 505 73
|
Flange assy. |
1 |
InternBDB: 70.209/455/3-4110:00 | InternKon: 70.209/455/4-4100:00 / 1
|
|
|
|
02 |
794 274 73
|
Flange assy. |
1 |
InternBDB: 70.209/655/5-4120:00 | InternKon: 70.209/455/4-4100:00 / 2
|
|
|
|
03 |
795 506 73
|
Heater |
1 |
InternBDB: LH-3002 TK 230 V / 500W | InternKon: 70.209/455/4-4100:00 / 3
|
|
|
|
04 |
769 268 73
|
Thread pin |
3 |
InternBDB: 70.209/655/1-4100:05 | InternKon: 70.209/455/4-4100:00 / 4
|
|
|
|
05 |
764 986 73
|
Pin SW 27 |
3 |
InternBDB: 70.209/655/1-4100:08 | InternKon: 70.209/455/4-4100:00 / 5
|
|
|
|
06 |
770 205 73
|
Slip ring 200 A |
1 |
InternBDB: 70.209/655/3-4100.12 | InternKon: 70.209/455/4-4100:00 / 6
|
|
|
|
07 |
764 983 73
|
Slip ring 400 A |
4 |
InternBDB: 070.900:1000-00 | InternKon: 70.209/455/4-4100:00 / 7
|
|
|
|
08 |
764 976 73
|
Insulating disc |
8 |
InternBDB: 70.209/655/1-4100:01 | InternKon: 70.209/455/4-4100:00 / 8
|
|
|
|
09 |
794 275 73
|
Ground pin SW 27 |
3 |
InternBDB: 70.209/655/5-4100:06 | InternKon: 70.209/455/4-4100:00 / 9
|
|
|
|
10 |
793 841 73
|
Pin SW 27 |
12 |
InternBDB: 70.209/455/3-4100:07 | InternKon: 70.209/455/4-4100:00 / 10
|
|
|
|
11 |
511 859 98
|
Thread pin 16x40 |
12 |
InternBDB: 70.209/655/1-4100:11 | InternKon: 70.209/455/4-4100:00 / 11
|
|
|
|
12 |
764 988 73
|
Bushing |
15 |
InternBDB: 70.209/655/1-4100:10 | InternKon: 70.209/455/4-4100:00 / 12
|
|
|
|
13 |
764 981 73
|
1,5 KV Support, inside 65x60 |
24 |
InternBDB: Isolator mit Tropfkante Nr.: 201 94 24 | InternKon: 70.209/455/4-4100:00 / 13
|
|
|
|
14 |
764 980 73
|
1,5 KV Insulator 60x50 |
3 |
InternBDB: Isolator Nr. 2019252 | InternKon: 70.209/455/4-4100:00 / 14
|
|
|
|
15 |
512 466 98
|
Nut |
3 |
InternBDB: M 16 /982 | InternKon: 70.209/455/4-4100:00 / 15
|
|
|
|
16 |
332 336 99
|
Nut |
6 |
InternBDB: M 16 /934 | InternKon: 70.209/455/4-4100:00 / 16
|
|
|
|
17 |
307 822 99
|
Bolt |
3 |
InternBDB: M16x30 /933 | InternKon: 70.209/455/4-4100:00 / 17
|
|
|
|
18 |
343 817 99
|
Lock washer |
3 |
InternBDB: B 16 /127 | InternKon: 70.209/455/4-4100:00 / 18
|
|
|
|
19 |
340 507 99
|
Washer |
1 |
InternBDB: DIN 125 - A 8.4 | InternKon: 70.209/455/4-4100:00 / 19
|
|
|
|
20 |
307 754 99
|
Bolt |
1 |
InternBDB: M 8x25 /933 | InternKon: 70.209/455/4-4100:00 / 20
|
|
|
|
21 |
343 109 99
|
Lock washer |
1 |
InternBDB: B 8 - FST /127 | InternKon: 70.209/455/4-4100:00 / 21
|
|
|
|
22 |
793 842 73
|
Adapter angle |
1 |
InternBDB: 70.209/455/3-4100:12 | InternKon: 70.209/455/4-4100:00 / 22
|
|
|
|
23 |
307 802 99
|
Bolt |
1 |
InternBDB: M12x25 | InternKon: 70.209/455/4-4100:00 / 23
|
|
|
|
24 |
504 271 98
|
Lock washer |
8 |
InternBDB: B 12 - FST /127 | InternKon: 70.209/455/4-4100:00 / 24
|
|
|
|
25 |
512 276 98
|
Washer |
8 |
InternBDB: A 13 /125 | InternKon: 70.209/455/4-4100:00 / 25
|
|
|
|
26 |
307 805 99
|
Bolt |
4 |
InternBDB: M12x35 | InternKon: 70.209/455/4-4100:00 / 26
|
|
|
|
27 |
332 334 99
|
Nut |
4 |
InternBDB: M12/934 | InternKon: 70.209/455/4-4100:00 / 27
|
|
|
|
28 |
332 334 99
|
Nut |
4 |
InternBDB: M12/934 | InternKon: 70.209/455/4-4100:00 / 28
|
|
|
|
29 |
516 093 98
|
Thread pin |
4 |
InternBDB: M12x35/916 | InternKon: 70.209/455/4-4100:00 / 29
|
|
|
|
30 |
907 690 40
|
Cable union |
1 |
InternBDB: BVNV -M253 M25x1,5 11-16mm Dichtbereich | InternKon: 70.209/455/4-4100:00 / 30
|
|
|
|
31 |
343 105 99
|
Lock washer |
2 |
InternBDB: B 5/127 | InternKon: 70.209/455/4-4100:00 / 31
|
|
|
|
32 |
307 679 99
|
Bolt |
2 |
InternBDB: M5x12/933 | InternKon: 70.209/455/4-4100:00 / 32
|
|
