PC5500-6E S/N 15060

Komatsu parts book diagram for PC5500-6E S/N 15060: AUTOMATIC CUT OFF - CABLE DRUM

01 02 03 04 05 06 07 08 20

	#	Part Number	Partname	Quantity	Options	Reference
	01	794 284 73	Bearing flange	2	InternBDB: 70.209/655/5-0800:01 \| InternKon: E70209_455_5_0800_00 / 1
	02	517 615 98	Roller bearing	2	InternBDB: DIN 625 - 62208-2RS \| InternKon: E70209_455_5_0800_00 / 2
	03	796 116 73	Lever 01 assy.	1	InternBDB: 70.209/455/5-0810:00 \| InternKon: E70209_455_5_0800_00 / 3
	04	796 117 73	Lever 02 assy.	1	InternBDB: 70.209/455/5-0840:00 \| InternKon: E70209_455_5_0800_00 / 4
	05	342 540 99	Circlip	4	InternBDB: DIN 471 - 40x1,75 \| InternKon: E70209_455_5_0800_00 / 5
	06	794 288 73	Pipe assy.	1	InternBDB: 70.209/655/5-0820:00 \| InternKon: E70209_455_5_0800_00 / 6
	07	307 830 99	Bolt	2	InternBDB: M16x70 /933 \| InternKon: E70209_455_5_0800_00 / 7
	08	334 601 99	Nut	4	InternBDB: M 16 /985 \| InternKon: E70209_455_5_0800_00 / 8
	20			-2	InternBDB: 70.209/455/6-0000:00
	20	796 115 73	Cut-off device - cable drum	1	InternBDB: 70.209/455/5-0800:00 \| InternKon: E70209_455_5_0800_00 / 16

Komatsu PC5500-6E S/N 15060 parts catalog PDF

AUTOMATIC CUT OFF - CABLE DRUM (991-0762) in PC5500-6E S/N 15060. Diagram image and parts list.
