01 |
769 255 73
|
Fixture assy. |
1 |
InternBDB: 70.209/655/1-2100:00 | InternKon: E70209_455_6_2000_00 / 1
|
|
|
|
02 |
796 122 73
|
Conduction supply |
1 |
InternBDB: 70.209/455/5-2200:00 | InternKon: E70209_455_6_2000_00 / 2
|
|
|
|
03 |
796 098 73
|
Cable union |
1 |
InternBDB: RS 125 | InternKon: E70209_455_6_2000_00 / 3
|
|
|
|
04 |
769 254 73
|
Catch |
1 |
InternBDB: 70.209/655/1-2000:05 | InternKon: E70209_455_6_2000_00 / 4
|
|
|
|
05 |
332 334 99
|
Nut |
2 |
InternBDB: M 12 / ISO 4032 | InternKon: E70209_455_6_2000_00 / 5
|
|
|
|
06 |
307 807 99
|
Bolt |
2 |
InternBDB: M 12 X 45 / ISO 4017 | InternKon: E70209_455_6_2000_00 / 6
|
|
|
|
07 |
769 253 73
|
Sleeve shaft |
1 |
InternBDB: 70.209/655/1-2000:01 NT | InternKon: E70209_455_6_2000_00 / 7
|
|
|
|
08 |
765 179 73
|
sprocket 200-501-060 |
1 |
InternBDB: 70.209/655/1-0120:02 | InternKon: E70209_455_6_2000_00 / 8
|
|
|
|
09 |
794 170 73
|
sprocket 200-301-052 |
1 |
InternBDB: 70.209/655/4/3-0110:02 | InternKon: E70209_455_6_2000_00 / 9
|
|
|
|
10 |
307 847 99
|
Bolt |
2 |
InternBDB: M 20 X 60 | InternKon: E70209_455_6_2000_00 / 10
|
|
|
|
11 |
512 477 98
|
Nut |
2 |
InternBDB: M 20 | InternKon: E70209_455_6_2000_00 / 11
|
|
|
|
12 |
795 514 73
|
Sprocket flange |
1 |
InternBDB: 70.209/655/4-3-2000:02 | InternKon: E70209_455_6_2000_00 / 12
|
|
|
|
13 |
794 156 73
|
Bearing retainer |
1 |
InternBDB: 70.209/655/4-3-2000:03 | InternKon: E70209_455_6_2000_00 / 13
|
|
|
|
14 |
765 249 73
|
Bearing cap |
1 |
InternBDB: 70.209/655/1-2000:04 | InternKon: E70209_455_6_2000_00 / 14
|
|
|
|
15 |
360 690 99
|
Felt ring |
1 |
InternBDB: DIN 5419 d=125; D=153; b=11 | InternKon: E70209_455_6_2000_00 / 15
|
|
|
|
16 |
761 244 73
|
Seal |
2 |
InternBDB: 6222, D=184; d=110 | InternKon: E70209_455_6_2000_00 / 16
|
|
|
|
17 |
502 230 98
|
Self-aligning bearing |
1 |
InternBDB: DIN 630 - 1222 | InternKon: E70209_455_6_2000_00 / 17
|
|
|
|
18 |
342 572 99
|
Circlip |
1 |
InternBDB: 110 X 4 / DIN 471 ? A2 | InternKon: E70209_455_6_2000_00 / 18
|
|
|
|
19 |
360 727 99
|
Felt ring |
1 |
InternBDB: DIN 5419 d=110; D=134 | InternKon: E70209_455_6_2000_00 / 19
|
|
|
|
20 |
307 756 99
|
Bolt |
6 |
InternBDB: M 8 X 30 / ISO 4017 | InternKon: E70209_455_6_2000_00 / 20
|
|
|
|
21 |
343 109 99
|
Lock washer |
6 |
InternBDB: B 8 / DIN 127 - FST | InternKon: E70209_455_6_2000_00 / 21
|
|
|
|
22 |
319 437 99
|
Bolt |
12 |
InternBDB: DIN 912 - M 12 X 55-10.9 | InternKon: E70209_455_6_2000_00 / 22
|
|
|
|
23 |
343 113 99
|
Lock washer |
18 |
InternBDB: 12 / DIN 127 - FST | InternKon: E70209_455_6_2000_00 / 23
|
|
|
|
24 |
307 805 99
|
Bolt |
6 |
InternBDB: M 12 X 35 / ISO 4017 | InternKon: E70209_455_6_2000_00 / 24
|
|
|
|
30 |
796 516 73
|
Drum bearing - pinion end |
-2 |
InternBDB: 70.209/455/6-2000:00
|
|
