793 604 73
|
Bake assy |
1 |
InternBDB: 16211140 / GFY 300 A 1048
|
|
|
|
? |
757 361 73
|
Disk carrier |
1 |
InternBDB: 16929197 | InternKon: 16211140 7 / 1
|
|
|
|
? |
763 744 73
|
Piston |
1 |
InternBDB: 16929048 | InternKon: 16211140 7 / 2
|
|
|
|
? |
806 321 73
|
Ring |
1 |
InternBDB: 16929198 | InternKon: 16211140 7 / 3
|
|
|
|
? |
757 352 73
|
Pressure plate |
1 |
InternBDB: 16929199 | InternKon: 16211140 7 / 4
|
|
|
|
? |
757 363 73
|
Cam |
1 |
InternBDB: 16929200 | InternKon: 16211140 7 / 5
|
|
|
|
? |
768 162 73
|
Internal disk |
6 |
InternBDB: 16103101 | InternKon: 16211140 7 / 6
|
|
|
|
? |
968 524
|
Outer disk |
7 |
InternBDB: 16103067 | InternKon: 16211140 7 / 7
|
|
|
|
? |
517 925 98
|
Compression spring |
36 |
InternBDB: 16423336 / 2,5x11,5x54 / DIN 2098 | InternKon: 16211140 7 / 8
|
|
|
|
? |
517 926 98
|
Compression spring |
18 |
InternBDB: 16423337 / 1,6x6,5x54 / DIN 2098 | InternKon: 16211140 7 / 9
|
|
|
|
? |
502 169 98
|
O-ring |
1 |
InternBDB: 16463282 / 250x3 / DIN 3771 | InternKon: 16211140 7 / 10
|
|
|
|
? |
972 122
|
O-ring |
1 |
InternBDB: 16463283 / 280x3 / DIN 3771 | InternKon: 16211140 7 / 11
|
|
|
|
? |
972 111
|
O-ring |
1 |
InternBDB: 16463292 / 270x3 DIN 3771 | InternKon: 16211140 7 / 12
|
|
|
|
? |
342 702 99
|
Circlip |
1 |
InternBDB: 16452340 / 250x5 /472 | InternKon: 16211140 7 / 13
|
|
|
|
? |
342 701 99
|
Circlip |
1 |
InternBDB: 16452335 / 240x5 /472 | InternKon: 16211140 7 / 14
|
|
|
|
? |
517 921 98
|
Shaft seal |
2 |
InternBDB: 16461205 / 75x100x10 C2 / DIN 3760 / | InternKon: 16211140 7 / 15
|
|
|
|
? |
793 662 73
|
Plug |
1 |
InternBDB: 16469074 / GPN 300 F 18 LF | InternKon: 16211140 7 / 16
|
|
|
|
? |
797 873 73
|
Quadring |
1 |
InternBDB: 16461527 / 4370 366Y | InternKon: 16211140 7 / 17
|
|
|
|
? |
968 526
|
Support ring |
2 |
InternBDB: 16461550 / 210x219,4x 1,4 P | InternKon: 16211140 7 / 18
|
|
|
|
? |
968 527
|
Quadring |
1 |
InternBDB: 4373 446 A / 461 528 | InternKon: 16211140 7 / 19
|
|
|
|
? |
968 528
|
Support ring |
2 |
InternBDB: 16461551 / 232,5x242x 1,4 P | InternKon: 16211140 7 / 20
|
|
|
|
? |
313 267 99
|
Plug |
9 |
InternBDB: 16444186 / M22x,15 /910 | InternKon: 16211140 7 / 21
|
|
|
|
? |
339 907 99
|
Seal ring |
9 |
InternBDB: A22x27 /7603 / 462 045 | InternKon: 16211140 7 / 22
|
|
|
|
? |
793 108 73
|
Disk assy with springs |
1 |
InternBDB: 570 829
|
|
|
|
? |
793 109 73
|
Seal Kit Brake |
1 |
InternBDB: 570 830
|
|
