01 |
796 486 73
|
Drum assy. |
1 |
InternBDB: 70.209/655/10-1000.00 | InternKon: 70.209/655/10-0000.00 / 3
|
|
|
|
02 |
796 490 73
|
Drum sheet casing |
1 |
InternBDB: 70.209/655/10-1300.00 | InternKon: 70.209/655/6-1000.00 / 2
|
|
|
|
03 |
794 152 73
|
Housing cover |
2 |
InternBDB: 70.209/655/4-1000.01 | InternKon: 70.209/655/6-1000.00 / 3
|
|
|
|
04 |
516 085 98
|
Lock bolt |
32 |
InternBDB: M8x20 WN 010 845 99 8.8 | InternKon: 70.209/655/6-1000.00 / 4
|
|
|
|
05 |
769 224 73
|
Warning plate 300x100 attention - high voltage |
2 |
InternKon: 70.209/655/6-1000.00 / 5
|
|
|
|
06 |
769 223 73
|
Warning plate 100x100 voltage assy. |
2 |
InternKon: 70.209/655/6-1000.00 / 6
|
|
|
|
07 |
769 225 73
|
Rating plate 148x75, brass |
1 |
InternKon: 70.209/655/6-1000.00 / 7
|
|
|
|
08 |
004 387 98
|
Union |
8 |
InternBDB: Pg 21 | InternKon: 70.209/655/6-1000.00 / 8
|
|
|
|
09 |
510 867 98
|
Clamp set |
4 |
InternBDB: RCP-nach TL | InternKon: 70.209/655/6-1000.00 / 9
|
|
|
|
10 |
500 398 98
|
Cover plate |
2 |
InternBDB: DP-C5 | InternKon: 70.209/655/6-1000.00 / 10
|
|
|
|
11 |
308 641 99
|
Bolt |
4 |
InternBDB: M16x130 ISO4014 | InternKon: 70.209/655/6-1000.00 / 11
|
|
|
|
12 |
906 769 40
|
Bushing clamp |
1 |
InternBDB: 16mmІ Serie 283 | InternKon: 70.209/655/6-1000.00 / 12
|
|
|
|
13 |
906 773 40
|
Cover plate |
1 |
InternBDB: 16mmІ | InternKon: 70.209/655/6-1000.00 / 13
|
|
|
|
14 |
356 265 40
|
Clamp |
2 |
InternBDB: TS35/7,5 116535-04 | InternKon: 70.209/655/6-1000.00 / 14
|
|
