01 |
939 081 40
|
Harness - Transfusing ump |
1 |
InternKon: 939 080 40 / 1
|
|
|
|
02 |
0443451910
|
Clip NW 19 |
15 |
InternBDB: 77 KES 04434 | InternKon: 939 080 40 / 2
|
|
|
|
03 |
321 015 99
|
Screw |
4 |
InternBDB: M 6 X25 4.8 B2E DIN 00084 | InternKon: 939 080 40 / 3
|
|
|
|
04 |
655 651 40
|
Cable protection hose DN 17 |
-2 |
InternBDB: NW 17 VCSG-17B | InternKon: 939 081 40 / 1
|
|
|
|
05 |
907 478 40
|
Cable union DN 17 |
3 |
InternBDB: NW 17 GERADE BVNV-M207 2x 938 302 40/2 | InternKon: 939 081 40 / 2
|
|
|
|
06 |
655 650 40
|
Cable protection hose DN 12 |
-2 |
InternBDB: NW 12 VCST-12B | InternKon: 939 081 40 / 3
|
|
|
|
07 |
907 623 40
|
Cable union NW 12 |
2 |
InternBDB: NW 12 GERADE M20 BVNV-M202 1x 938 302 40/3 | InternKon: 939 081 40 / 4
|
|
|
|
08 |
056 070 40
|
Cable sleeve 1,0-1,5 |
12 |
InternBDB: 1,0-1,5 | InternKon: 939 081 40 / 5
|
|
|
|
09 |
907 501 40
|
Wire end ferrule 10 qmm |
8 |
InternBDB: 10,0MM2 CE103D, 203178.16 | InternKon: 939 081 40 / 6
|
|
|
|
10 |
256 514 40
|
Plate |
3 |
InternBDB: 15X30X1,5 ALU | InternKon: 939 081 40 / 7
|
|
|
|
11 |
056 292 40
|
Cable strap |
3 |
InternBDB: TY 23 M | InternKon: 939 081 40 / 8
|
|
|
|
12 |
515 213 40
|
Cable 1,0 |
-2 |
InternBDB: 1,0MM2 BLAU | InternKon: 939 081 40 / 9
|
|
|
|
13 |
515 217 40
|
Cable 10,0 |
-2 |
InternBDB: 10,0MM2 SCHWARZ 091000SW | InternKon: 939 081 40 / 10
|
|
|
|
14 |
938 302 40
|
Distribution box consist of fig nos 17-24 |
1 |
InternKon: 939 081 40 / 11
|
|
|
|
15 |
944 781 40
|
Press botton assy. consist of fig nos. 25 + 26 |
1 |
InternKon: 939 081 40 / 12
|
|
|
|
16 |
517 322 98
|
Cable nut |
4 |
InternBDB: M20x1,5 CUZN39PB3 DINEN 50262 3x 938 302 40 /9 | InternKon: 939 081 40 / 13
|
|
|
|
17 |
270 282 40
|
Housing, empty |
1 |
InternBDB: A 120 | InternKon: 938 302 40 / 1
|
|
|
|
18 |
505 955 99
|
Assembly rail |
-2 |
InternBDB: TS 35X27X7,3 ST2LG BK DIN 46277 | InternKon: 938 302 40 / 4
|
|
|
|
19 |
906 612 40
|
Through clamp 2.5 |
2 |
InternBDB: 2,5MM2 870-531 | InternKon: 938 302 40 / 5
|
|
|
|
20 |
906 770 40
|
Through clamp 10,0 |
2 |
InternBDB: 10 MM2 284-901 | InternKon: 938 302 40 / 6
|
|
|
|
21 |
940 673 40
|
Clamp |
2 |
InternBDB: 1SNA206351R1600 BAM2 | InternKon: 938 302 40 / 7
|
|
|
|
22 |
319 056 99
|
Screw |
2 |
InternBDB: M 6 X 8 5.8 DIN 00084 | InternKon: 938 302 40 / 8
|
|
|
|
24 |
906 613 40
|
Cover plate |
1 |
InternBDB: 870-573 | InternKon: 938 302 40 / 11
|
|
|
|
25 |
906 774 40
|
Cover plate |
1 |
InternBDB: 10MM2 284-325 | InternKon: 938 302 40 / 12
|
|
|
|
26 |
940 726 40
|
Light switch |
1 |
InternBDB: Santon 51LC1K6 | InternKon: 944 781 40 / 1
|
|
|
|
27 |
321 010 99
|
Screw |
4 |
InternBDB: M 5 X25 4.8 B2E DIN 00084 | InternKon: 944 781 40 / 2
|
|
