01 |
939 084 40
|
Harness - control frame |
1 |
InternKon: 948 811 40 / 48
|
|
|
|
02 |
|
|
-2 |
|
|
|
|
02 |
907 692 40
|
Fitting PG 9 |
4 |
InternBDB: M16/NW12 BVIR-M162 | InternKon: 939 084 40 / 2
|
|
|
|
03 |
907 703 40
|
Cable union |
4 |
InternBDB: MEHRFACH 21650YNPM4X3 | InternKon: 939 084 40 / 3
|
|
|
|
04 |
940 461 40
|
Insulating tube B5x0,6 |
-2 |
InternBDB: B 5 X0,6 PUR 70 SHORE | InternKon: 939 084 40 / 4
|
|
|
|
05 |
256 514 40
|
Plate |
13 |
InternBDB: 15X30X1,5 ALU | InternKon: 939 084 40 / 5
|
|
|
|
06 |
056 292 40
|
Cable strap |
13 |
InternBDB: TY 23 M | InternKon: 939 084 40 / 6
|
|
|
|
07 |
906 922 40
|
Protection cap |
3 |
InternBDB: 1166621 003 | InternKon: 939 084 40 / 7
|
|
|
|
08 |
323 961 40
|
Sleeve 6,3x0,8 |
7 |
InternBDB: 6,3X0,8 35180 | InternKon: 939 084 40 / 8
|
|
|
|
10 |
907 480 40
|
Cable union DN 10-90 |
1 |
InternBDB: NW 10 90' BVWV-M160 | InternKon: 939 084 40 / 10
|
|
|
|
11 |
655 631 40
|
Pipe adapter DN 12/10 |
1 |
InternBDB: NW 12/10 BAVR-12T10T | InternKon: 939 084 40 / 11
|
|
|
|
12 |
906 420 40
|
T-Distributor DN 12 |
4 |
InternBDB: NW 12 BFTL-121212TTT | InternKon: 939 084 40 / 12
|
|
|
|
13 |
655 633 40
|
Pipe adapter DN 17/12 |
2 |
InternBDB: NW 17/12 BAVR-17G12T | InternKon: 939 084 40 / 13
|
|
|
|
14 |
655 629 40
|
T-Distributor DN 17 |
1 |
InternBDB: NW 17 BFTL-171717GGG | InternKon: 939 084 40 / 14
|
|
|
|
15 |
655 627 40
|
Distributor DN 23/17 |
1 |
InternBDB: NW 23/17 BVYR-231717GGG | InternKon: 939 084 40 / 15
|
|
|
|
16 |
907 623 40
|
Cable union NW 12 |
1 |
InternBDB: NW 12 GERADE M20 BVNV-M202 | InternKon: 939 084 40 / 16
|
|
|
|
17 |
896 520 40
|
End pin |
2 |
InternBDB: BO 3,0X25 | InternKon: 939 084 40 / 17
|
|
|
|
18 |
907 693 40
|
Fitting PG 16 |
1 |
InternBDB: M20/NW17 BVIR-M207 | InternKon: 939 084 40 / 18
|
|
|
|
19 |
907 708 40
|
Cable union |
1 |
InternBDB: MEHRFACH 22052YNPM6X2,5 | InternKon: 939 084 40 / 19
|
|
|
|
20 |
655 649 40
|
Cable protection hose DN 10 |
-2 |
InternBDB: NW 10 VCST-10B | InternKon: 939 084 40 / 20
|
|
|
|
21 |
655 650 40
|
Cable protection hose DN 12 |
-2 |
InternBDB: NW 12 VCST-12B | InternKon: 939 084 40 / 21
|
|
|
|
22 |
655 651 40
|
Cable protection hose DN 17 |
-2 |
InternBDB: NW 17 VCSG-17B | InternKon: 939 084 40 / 22
|
|
|
|
23 |
655 652 40
|
Cable protection hose DN 23 |
-2 |
InternBDB: NW 23 VCSG-23B | InternKon: 939 084 40 / 23
|
|
|
|
24 |
907 980 40
|
Fitting DN 23 |
1 |
InternBDB: NW 23 BVIVG-U353 | InternKon: 939 084 40 / 24
|
|
|
|
25 |
515 213 40
|
Cable 1,0 |
-2 |
InternBDB: 1,0MM2 BLAU | InternKon: 939 084 40 / 25
|
|
|
|
26 |
795 129 73
|
Plug |
1 |
InternBDB: HD36-24-31PE-059 KES 08191 0819191206 | InternKon: 939 084 40 / 26
|
|
|
|
27 |
795 157 73
|
Pin |
23 |
InternBDB: 0460-202-16141 KES 08191 0819105320 | InternKon: 939 084 40 / 27
|
|
|
|
28 |
940 852 40
|
Plug |
8 |
InternBDB: #16 DVI 61103-20 | InternKon: 939 084 40 / 28
|
|
|
|
29 |
517 321 98
|
Cable nut |
1 |
InternBDB: M16x1,5 CUZN39PB3 DINEN 50262 | InternKon: 939 084 40 / 29
|
|
|
|
30 |
517 322 98
|
Cable nut |
1 |
InternBDB: M20x1,5 CUZN39PB3 DINEN 50262 | InternKon: 939 084 40 / 30
|
|
|
|
33 |
056 070 40
|
Cable sleeve 1,0-1,5 |
2 |
InternBDB: 1,0-1,5 | InternKon: 939 084 40 / 33
|
|
|
|
34 |
940 629 40
|
Warmth shrink hose |
-2 |
InternBDB: .05060 91F2570 | InternKon: 939 084 40 / 34
|
|
|
|
35 |
795 132 73
|
Plug assy. |
7 |
InternBDB: KES 08192 0819212920 | InternKon: 939 084 40 / 1
|
|
