01 |
948 856 40
|
Harness - pressure contact - h.p. filter |
1 |
InternKon: 948 855 40 / 1
|
|
|
|
02 |
795 134 73
|
Plug assy. 3-pole |
3 |
InternBDB: KES 08192 0819213920 | InternKon: 948 856 40 / 2
|
|
|
|
03 |
906 079 40
|
T-Distributor |
2 |
InternBDB: BFTL 29 29 29 GGG | InternKon: 948 856 40 / 10
|
|
|
|
04 |
907 703 40
|
Cable union |
2 |
InternBDB: Pflitsch 21650 YNPM 4x3 | InternKon: 948 856 40 / 9
|
|
|
|
05 |
907 692 40
|
Fitting PG 9 |
2 |
InternBDB: PMA BVIR - M 162 | InternKon: 948 856 40 / 8
|
|
|
|
06 |
907 733 40
|
T-Distributor DN 23 |
1 |
InternBDB: NW 23 BVTR-232323 | InternKon: 948 856 40 / 11
|
|
|
|
07 |
655 634 40
|
Pipe adapter DN 23/17 |
1 |
InternBDB: BAVR-23 G 17 G | InternKon: 948 856 40 / 15
|
|
|
|
08 |
655 652 40
|
Protecting hose DN 23 |
-2 |
InternBDB: PMA VCSG-23B | InternKon: 948 856 40 / 19
|
|
|
|
09 |
256 514 40
|
Name plate |
10 |
InternKon: 948 856 40 / 5
|
|
|
|
10 |
056 292 40
|
Cable strap |
10 |
InternBDB: TY 23M | InternKon: 948 856 40 / 6
|
|
|
|
11 |
940 169 40
|
Cable 4x1 |
-2 |
InternKon: 948 856 40 / 23
|
|
|
|
12 |
795 152 73
|
Pressure switch with plug assy. |
3 |
InternBDB: 7861931650 | InternKon: 948 855 40 / 10
|
|
|
|
13 |
655 635 40
|
Pipe adapter DN 29/17 |
2 |
InternBDB: BAVR 29G 17G | InternKon: 948 856 40 / 13
|
|
|
|
14 |
940 452 40
|
Fitting M17/M25 |
1 |
InternBDB: M17/M25 BFIL-M257 METRISCH * | InternKon: 948 856 40 / 16
|
|
|
|
15 |
795 129 73
|
Plug |
1 |
InternBDB: Deutsch HD36-24-31PE-059 0819191206 | InternKon: 948 856 40 / 21
|
|
|
|
16 |
940 462 40
|
Insulating tube |
-2 |
InternBDB: B 6 X0,6 PUR 70 SHORE | InternKon: 948 856 40 / 7
|
|
|
|
17 |
655 650 40
|
Protecting hose DN 12 |
-2 |
InternBDB: VCST - 12 B | InternKon: 948 856 40 / 17
|
|
|
|
18 |
655 651 40
|
Protecting hose DN 17 |
-2 |
InternBDB: VCST-17B | InternKon: 948 856 40 / 18
|
|
|
|
19 |
655 696 40
|
Protecting hose DN 29 |
-2 |
InternBDB: VCST-29B | InternKon: 948 856 40 / 20
|
|
|
|
20 |
907 693 40
|
Fitting PG 16 |
2 |
InternBDB: BVIR-M207 | InternKon: 948 856 40 / 3
|
|
|
|
21 |
907 705 40
|
Cable union |
2 |
InternBDB: Pflitsch 22051YNPM5x2,5 | InternKon: 948 856 40 / 4
|
|
|
|
22 |
906 420 40
|
T-Distributor |
1 |
InternBDB: BFTL-12 12 12TTT | InternKon: 948 856 40 / 12
|
|
|
|
23 |
896 558 40
|
Pipe adapter DN 29/23 |
1 |
InternBDB: BAVR-29 G 23 G | InternKon: 948 856 40 / 14
|
|
|
|
24 |
795 132 73
|
Plug assy. 2-pole |
6 |
InternBDB: 0819212920 | InternKon: 948 856 40 / 1
|
|
|
|
25 |
515 213 40
|
Cable 1,0 |
-2 |
InternKon: 948 856 40 / 24
|
|
|
|
26 |
795 123 73
|
Pin |
24 |
InternBDB: Deutsch 0460-202-16141 0819105320 | InternKon: 948 856 40 / 22
|
|
|
|
27 |
0443453211
|
Clip |
22 |
InternKon: 948 855 40 / 2
|
|
|
|
28 |
340 465 99
|
Washer |
18 |
InternBDB: 10,5/125 | InternKon: 948 855 40 / 3
|
|
|
|
29 |
507 037 98
|
Nut |
18 |
InternBDB: M10/985 | InternKon: 948 855 40 / 4
|
|
|
|
30 |
0443452110
|
Clip |
1 |
InternKon: 948 855 40 / 8
|
|
|
|
31 |
0819320010
|
Clip |
5 |
InternKon: 948 855 40 / 9
|
|
|
|
32 |
302 579 99
|
Bolt |
6 |
InternBDB: M10x280/931 | InternKon: 948 855 40 / 5
|
|
|
|
33 |
517 122 98
|
Lock washer |
6 |
InternBDB: 10 WN 655 938 40 | InternKon: 948 855 40 / 6
|
|
|
|
34 |
933 369 40
|
Pipe 240lg |
6 |
InternBDB: 30x5x240 | InternKon: 948 855 40 / 7
|
|
|
|
35 |
0443451510
|
Clip |
7 |
InternKon: 948 855 40 / 15
|
|
|
|
36 |
510 748 98
|
Resilent sleeve 20lg |
4 |
InternBDB: 13/25x20 WN 341 948 40 | InternKon: 948 855 40 / 12
|
|
|
|
38 |
0443452711
|
Clip |
3 |
InternKon: 948 855 40 / 11
|
|
|
|
39 |
307 779 99
|
Bolt |
5 |
InternBDB: M10x30/933 | InternKon: 948 855 40 / 14
|
|
|
|
40 |
940 852 40
|
Sealing plug |
7 |
InternBDB: 16 DVI Deutsch 61103-20 | InternKon: 948 856 40 / 25
|
|
|
|
41 |
907 981 40
|
Fitting DN 29 |
1 |
InternBDB: BVIVG-U359 | InternKon: 948 856 40 / 26
|
|
|
|
42 |
907 971 40
|
Pipe adapter DN 23/12 |
1 |
InternBDB: NW 23/12 BAVR-23/12 | InternKon: 948 856 40 / 27
|
|
|
|
43 |
907 709 40
|
Cable union PG 16 |
1 |
InternBDB: MEHRFACH 22553YNPM13X2,7 | InternKon: 948 856 40 / 28
|
|
|
|
44 |
896 520 40
|
Plug pin |
10 |
InternBDB: BO 3,0x25 | InternKon: 948 856 40 / 29
|
|
|
|
45 |
940 461 40
|
Insulating tube B5x0,6 |
-2 |
InternBDB: B 5 X0,6 PUR 70 SHORE | InternKon: 948 856 40 / 30
|
|
|
|
46 |
940 914 40
|
Warmth shrink hose |
-2 |
InternBDB: H3/ 8 V 9,5 N 4,8 W 0,6 | InternKon: 948 856 40 / 31
|
|
|
|
47 |
940 909 40
|
Warmth shrink hose |
-2 |
InternBDB: H1/16 V 1,6 N 0,8 W 0,4 | InternKon: 948 856 40 / 32
|
|
|
|
48 |
940 629 40
|
Warmth shrink hose |
-2 |
InternBDB: .05060 91F2570 | InternKon: 948 856 40 / 33
|
|
|
|
49 |
350 768 99
|
Washer |
6 |
InternBDB: R11,0 ST DIN 00440 | InternKon: 948 855 40 / 17
|
|
|
|
50 |
0443453411
|
Clip NW 34 |
1 |
InternBDB: KES 04434 | InternKon: 948 855 40 / 18
|
|
|
|
51 |
512 958 98
|
Resilient sleeve 45lg |
1 |
InternBDB: 13 /25X 45 42CRMO4-TQ+T WN 34194840 | InternKon: 948 855 40 / 19
|
|
|
|
52 |
510 741 98
|
Resilient sleeve 50lg |
3 |
InternBDB: 13 /25X 50 42CRMO4-TQ+T WN 34194840 | InternKon: 948 855 40 / 20
|
|
