PC3000-6E S/N 06262

01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67

#	Part Number	Partname	Quantity	Options	Reference
01	946 493 40	Slip ring	1	InternBDB: Bцhlitz-Ehrenberg 70.211/9/1-0000:00 \| InternKon: 946 491 40 / 4
02		Frame assy.	-2
03		Hood assy. with line entrance	-2		991-0816
04		Hood assy. with inspection glass	-2		991-0699
05		Current supply unit	-2		991-0817
06	795 565 73	Hood	1	InternBDB: 70.211/9-0100:00 \| InternKon: 70.211/9/1-0000:00 / 6
07	770 217 73	Sealing 3x12	-2	InternKon: 70.211/9/1-0000:00 / 7
08	505 955 99	Assembly rail TS 35	-2	InternKon: 70.211/9/1-0000:00 / 8
09	906 612 40	Throught clamp	19	InternBDB: Wago 870-531 \| InternKon: 70.211/9/1-0000:00 / 9
10	906 630 40	Protective wire clip	2	InternBDB: Wago 870-537 \| InternKon: 70.211/9/1-0000:00 / 10
11	906 769 40	Throught clamp	1	InternBDB: Wago 283-901 \| InternKon: 70.211/9/1-0000:00 / 11
12	004 387 98	Plug	4	InternBDB: NPG 21 /46320 \| InternKon: 70.211/9/1-0000:00 / 12
13	907 479 40	Cable union	3	InternBDB: 14 ? 21 mm Dichtbereich \| InternKon: 70.211/9/1-0000:00 / 13
14	313 541 99	Eyebolt	2	InternBDB: M 16 /580 \| InternKon: 70.211/9/1-0000:00 / 14
15	332 336 99	Nut	2	InternBDB: M 16 /934 \| InternKon: 70.211/9/1-0000:00 / 15
16	307 732 99	Bolt	1	InternBDB: M6x25 /933 \| InternKon: 70.211/9/1-0000:00 / 16
17	796 102 73	Angle with assembly rail	1	InternBDB: 70.211/11-0300:00 \| InternKon: 70.211/9/1-0000:00 / 17
18	795 540 73	Regulated radiator	1	InternBDB: Maxi-AL 230V /150W \| InternKon: 70.211/9/1-0000:00 / 18
19	765 986 73	Light	1	InternBDB: 1x18W /AEG Lichttechnick Galaxielux AWW 118 IND mit Leuchtstoffr \| InternKon: 70.211/9/1-0000:00 / 19
20	307 730 99	Bolt	2	InternBDB: M6x20 /933 \| InternKon: 70.211/9/1-0000:00 / 20
21	512 465 98	Nut	2	InternBDB: M 6 /982 \| InternKon: 70.211/9/1-0000:00 / 21
22	795 506 73	Heater 230V/500W	2	InternBDB: LH-3002TK230V500W \| InternKon: 70.211/9/1-0000:00 / 22
23	319 025 99	Bolt	2	InternBDB: M5x20/84 \| InternKon: 70.211/9/1-0000:00 / 23
24	764 584 73	Switch	2	InternBDB: GC-U1 VT \| InternKon: 70.211/9/1-0000:00 / 24
25	770 220 73	Switch retainer	2	InternBDB: 70.211/5-0000:03 \| InternKon: 70.211/9/1-0000:00 / 25
26	343 106 99	Lock washer	2	InternBDB: B 6 /127 FST \| InternKon: 70.211/9/1-0000:00 / 26
27	377 750 99	Bolt	6	InternBDB: M8x18 /933 \| InternKon: 70.211/9/1-0000:00 / 27
28	319 561 99	Screw	4	InternBDB: M4x40 /912 \| InternKon: 70.211/9/1-0000:00 / 28
29	307 805 99	Bolt	8	InternBDB: M12x35 /933 \| InternKon: 70.211/9/1-0000:00 / 29
30	765 568 73	Cable retainer	1	InternBDB: 70.211/1-0000:10 \| InternKon: 70.211/9/1-0000:00 / 30
31	346 510 99	Lock washer	10	InternBDB: B 8 /127 FST \| InternKon: 70.211/9/1-0000:00 / 31
32	307 752 99	Bolt	4	InternBDB: M8x20 /933 \| InternKon: 70.211/9/1-0000:00 / 32
33	770 221 73	Transformer 0,1 KV	1	InternBDB: BV EI/84b/277V/230V/60Hz \| InternKon: 70.211/9/1-0000:00 / 33
34	320 005 99	Screw	13	InternBDB: M4x16 /912 \| InternKon: 70.211/9/1-0000:00 / 34
35	340 459 99	Washer	4	InternBDB: A 4,3 /125 \| InternKon: 70.211/9/1-0000:00 / 35
36	343 092 99	Lock washer	37	InternBDB: B 4 /127 FST \| InternKon: 70.211/9/1-0000:00 / 36
37	332 078 99	Nut	29	InternBDB: M 4 /934 \| InternKon: 70.211/9/1-0000:00 / 37
38	765 569 73	Hose (polyethylen)	-2	InternKon: 70.211/9/1-0000:00 / 38
39	765 560 73	Union	4	InternBDB: GE 04 LLM A3C \| InternKon: 70.211/9/1-0000:00 / 39
40	350 560 99	Grease nipple	4	InternBDB: AM 6 /71412 \| InternKon: 70.211/9/1-0000:00 / 40
41	270 873 40	Cable channel	-2	InternBDB: 40x40 /BA 640 0040 Tehalit \| InternKon: 70.211/9/1-0000:00 / 41
42	307 756 99	Bolt	4	InternBDB: M8x30 /933 \| InternKon: 70.211/9/1-0000:00 / 42
43	340 507 99	Washer	4	InternBDB: 8,4 /125 \| InternKon: 70.211/9/1-0000:00 / 43
44	512 557 98	Nut	4	InternBDB: M 8 /982 \| InternKon: 70.211/9/1-0000:00 / 44
45	512 466 98	Nut	4	InternBDB: M 16 /982 \| InternKon: 70.211/9/1-0000:00 / 45
46	340 469 99	Washer	4	InternBDB: B 17 /125 \| InternKon: 70.211/9/1-0000:00 / 46
47	307 824 99	Bolt	4	InternBDB: M16x40 /933 \| InternKon: 70.211/9/1-0000:00 / 47
48	764 607 73	Ball bearing	1	InternKon: 70.211/9/1-0000:00 / 48
49		Lower plate, weld on part	1	InternBDB: 70.211/9/1-1100:00 \| InternKon: 70.211/9/1-0000:00 / 49
50	511 459 98	Fuse screw	60	InternBDB: B 151 90 M8x16 /6921 \| InternKon: 70.211/9/1-0000:00 / 50
51	796 777 73	cable clamp	1	InternBDB: RS 75Roxtec - RS00100751 \| InternKon: 70.211/9/1-0000:00 / 51
52	318 367 99	Countersunk screw	8	InternBDB: M10x35 /7991 \| InternKon: 70.211/9/1-0000:00 / 52
53	507 037 98	Nut	8	InternBDB: M 10 /982 \| InternKon: 70.211/9/1-0000:00 / 53
54	765 560 73	Union	4	InternBDB: GE 04-LLM A3C \| InternKon: 70.211/9/1-0000:00 / 54
55	512 467 98	Nut	8	InternBDB: M 12 /982 \| InternKon: 70.211/9/1-0000:00 / 55
56		Ring body	1	InternBDB: 70.211/9/1-4000:00 \| InternKon: 70.211/9/1-0000:00 / 56	991-0818
57	343 095 99	Lock washer	3	InternBDB: B 10 /127 FST \| InternKon: 70.211/9/1-0000:00 / 57
58	307 781 99	Bolt	3	InternBDB: M10x40 /933 \| InternKon: 70.211/9/1-0000:00 / 58
59	307 679 99	Bold	4	InternBDB: M 5 X 12 ISO 4017 \| InternKon: 70.211/9/1-0000:00 / 59
60	512 470 98	Lock washer	6	InternBDB: B 5 DIN 127 \| InternKon: 70.211/9/1-0000:00 / 60
61	340 461 99	Washer	4	InternBDB: B 5.3 DIN 125 \| InternKon: 70.211/9/1-0000:00 / 61
62	270 873 40	Cable duct	-2	InternKon: 70.211/9/1-0000:00 / 62
63	356 265 40	Clamp	4	InternBDB: TS 35/7,5 \| InternKon: 70.211/9/1-0000:00 / 63
64	793 883 73	Fuse screw	4	InternBDB: M6x20 B 151 90 \| InternKon: 70.211/9/1-0000:00 / 64
65	906 613 40	Disconnect terminal	2	InternKon: 70.211/9/1-0000:00 / 65
66	318 044 99	Screw	4	InternBDB: M 4 X 12 ISO 1207 \| InternKon: 70.211/9/1-0000:00 / 66
67	319 003 99	Screw	11	InternBDB: M 4 X 8 ISO 1207 \| InternKon: 70.211/9/1-0000:00 / 67

Komatsu PC3000-6E S/N 06262 parts catalog PDF

SLIP RING (991-0876) in PC3000-6E S/N 06262. Diagram image and parts list.
