01 |
946 496 40
|
MS-Cable SS-M assy. |
1 |
InternBDB: ELIMO MS-KABEL SS-M D=48MM PC 3000- 6E | InternKon: 947 946 40 / 8
|
|
|
|
02 |
946 497 40
|
MS-Cable M-K assy. |
1 |
InternBDB: Elimo MS-KABEL M-K D=48 MM PC 3000- 6E | InternKon: 947 946 40 / 9
|
|
|
|
03 |
946 498 40
|
MS-Cable SRK-SS assy. |
1 |
InternBDB: Elimo MS-KABEL SRK-SS D=48 MM PC 3000- 6E | InternKon: 947 946 40 / 7
|
|
|
|
04 |
946 498 40
|
MS-Cable KK- SRK assy. |
1 |
InternBDB: Elimo MS-KABEL KK-SRK D=48 MM PC 3000- 6E | InternKon: 947 946 40 / 10
|
|
|
|
05 |
947 948 40
|
Retainer Engine |
1 |
InternKon: 947 946 40 / 1
|
|
|
|
06 |
947 947 40
|
Retainer Engine |
1 |
InternKon: 947 946 40 / 2
|
|
|
|
07 |
947 949 40
|
Clamp retainer |
1 |
InternKon: 947 946 40 / 4
|
|
|
|
08 |
939 071 40
|
Clamp retainer |
1 |
InternKon: 947 946 40 / 5
|
|
|
|
09 |
509 063 98
|
Clamp set |
26 |
InternBDB: S-4-G-45 PA DIN 03015 | InternKon: 939 074 40 / 1
|
|
|
|
10 |
534 009 99
|
Weld on plate |
23 |
InternBDB: S-AP-A-4 W1 DIN 03015 | InternKon: 939 074 40 / 2
|
|
|
|
11 |
534 008 99
|
Cover plate |
23 |
InternBDB: S-DP-A-4 W1 DIN 03015 | InternKon: 939 074 40 / 3
|
|
|
|
12 |
518 265 98
|
Clamp set |
26 |
InternBDB: S-4-R-48,3 PA DIN 03015 | InternKon: 939 074 40 / 4
|
|
|
|
13 |
308 612 99
|
Bolt |
46 |
InternBDB: M12X 100 8.8 DIN 00931 | InternKon: 939 074 40 / 5
|
|
|
|
14 |
504 787 98
|
Locking plate |
3 |
InternBDB: S-4 W1 DIN 03015 | InternKon: 939 074 40 / 6
|
|
|
|
15 |
509 308 98
|
Locking plate |
20 |
InternBDB: SG-BL S 2 UST1203 WN 01183999 | InternKon: 939 074 40 / 7
|
|
|
|
16 |
504 786 98
|
Screw |
6 |
InternBDB: S-4 W1 DIN 03015 | InternKon: 939 074 40 / 8
|
|
|
|
17 |
510 732 98
|
Resilient sleeve |
2 |
InternBDB: 21 /40X 60 42CRMO4-TQ+T WN 34194840 | InternKon: 939 074 40 / 9
|
|
|
|
18 |
510 730 98
|
Resilient sleeve |
4 |
InternBDB: 17 /30X 55 42CRMO4-TQ+T WN 34194840 | InternKon: 939 074 40 / 10
|
|
|
|
19 |
308 321 99
|
Bolt |
4 |
InternBDB: M16X 90 10.9 DIN 00931 | InternKon: 939 074 40 / 11
|
|
|
|
20 |
302 573 99
|
Bolt |
2 |
InternBDB: M20X 100 10.9 DIN 00931 | InternKon: 939 074 40 / 12
|
|
|
|
21 |
343 006 99
|
Washer |
6 |
InternBDB: SHB 13 ST1203 DIN 00093 | InternKon: 939 076 40 / 5
|
|
