RING BODY | PC3000-6E S/N 06262 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options
01	796 780 73	Ring body assy.	1	InternBDB: 70.211/9/1-0000:00
02	770 240 73	Ring group 1 (medium voltage) fig-nos. 03-22	1	InternBDB: 70.211/5-4100:00
03	765 626 73	Pin	3
04	765 625 73	Slip ring	4	InternBDB: 070.900:1000:00
05	770 241 73	Bushing	12	InternBDB: 70.211/5-4100:03
06	770 242 73	Flange assy.	1	InternBDB: 70.211/5-4110:00
07	765 275 73	Inside isolator 10 KV	18
08	765 633 73	Pin	9	InternBDB: 70.211/1-0200:03(4)
09	770 243 73	Loom	1	InternBDB: 70.211/5-4100:05
10	770 244 73	Flange assy.	1	InternBDB: 70.211/5-4120:00
11	307 829 99	Bolt	3	InternBDB: M16x65 /933
12	512 466 98	Nut	3	InternBDB: M 16 /982
13	307 779 99	Bolt	3	InternBDB: M10x30 /933
14	343 095 99	Lock washer	3	InternBDB: B 10 /127 FST
15	770 245 73	Connecting bracket	1	InternBDB: 70.211/5-4100:08
16	340 467 99	Washer	8	InternBDB: B 13 /125
17	343 113 99	Lock washer	8	InternBDB: B 12 /127 FST
18	307 802 99	Bolt	4	InternBDB: M12x25 /933
19	332 334 99	Nut	4	InternBDB: M 12 /934
20	307 805 99	Bolt	4	InternBDB: M12x35 /933
21	770 246 73	Connecting bracket	1	InternBDB: 70.211/5-4100:07
22	770 247 73	Connecting bracket	2	InternBDB: 70.211/5-4100:06
23	796 781 73	Ring group 2 (low voltage) Bild-Nr. 24-65	1	InternBDB: 70.211/9/1-4200:00
24	796 782 73	Flange	1	InternBDB: 70.211/9/1-4200:02
25	342 572 99	Circlip	1	InternBDB: 110x4 /471
26	511 462 98	Roller bearing	1	InternBDB: 61822 2RS /625
27	342 678 99	Circlip	1	InternBDB: 140x4 /472
28	770 250 73	Flange	1	InternBDB: 70.211/5-4200:01
29	770 251 73	Pin	3	InternBDB: 70.211/5-4200:03
30	770 252 73	Loom	3	InternBDB: 70.211/5-4200:04
31	332 336 99	Nut	2	InternBDB: M 16 /934
32	770 253 73	Collector rod	2	InternBDB: 70.211/5-4240:01
33	770 254 73	Loom	2	InternBDB: EGBS 214-1 70.211/5-4240:02
34	340 464 99	Washer	3	InternBDB: B 8,4 /125
35	512 557 98	Nut	3	InternBDB: M 8 /982
36	764 644 73	Insulating disc	14	InternBDB: geschlitzt
37	764 643 73	Slip ring	12	InternBDB: d=33 nach 423.080/21-1100:02
38	319 551 99	Screw	13	InternBDB: M5x8 /912
39	343 105 99	Lock washer	13	InternBDB: A 5 /127 FST
40	770 255 73	Slip ring	1	InternBDB: d=133 /M5 - versilbert 70.211/5-4200:05
41	770 256 73	Collector with graphit-carbon	1	InternBDB: 70.211/5-4251:01
42	770 257 73	Graphit-carbon	1	InternBDB: 70.211/5-4251:01
43	765 915 73	Collector fig-nos. 44-58	12	InternBDB: EST 63-00
44	764 630 73	Brush	12	InternBDB: fьr EST 63
45	770 258 73	Retainer	13	InternBDB: 834.080/11-1000:01
46	770 259 73	Draw spring	13	InternBDB: B 1,2x8,5x16
47	770 260 73	Adapter	13	InternBDB: 834.080/11-1000:02
48	770 261 73	Yoke	13	InternBDB: 834.080/11-1000:04
49	342 037 99	Cotter pin	13	InternBDB: 2,5x20 /94
50	770 262 73	Lever	26	InternBDB: 834.080/11-1000:03
51	770 263 73	Bar	39	InternBDB: 834.080/11-1000:05
52	307 732 99	Bolt	13	InternBDB: M6x25 /933
53	340 463 99	Washer	28	InternBDB: B 6,4 /125
54	343 085 99	Lock washer	28	InternBDB: B 6 /127 FST
55	332 331 99	Nut	26	InternBDB: M 6 /934
56	307 693 99	Bolt	13	InternBDB: M5x20 /933
57	332 292 99	Nut	13	InternBDB: M 5 /934
58	319 412 99	Screw	13	InternBDB: M5x10 /912
59	343 105 99	Lock washer	13	InternBDB: B 5 /127 FST
60	770 264 73	Holding plate	1	InternBDB: 70.211/5-4230:01
61	505 955 99	Assembly rail TS 35	-2
62	940 673 40	Clamp	2
63	906 612 40	Series terminal 2,5 qmm	13	InternBDB: Serie 281
64	307 727 99	Bolt	2	InternBDB: M6x12 /933
65	472 298 99	Threaded pipe PG 29	-2	InternBDB: 70.211/5-4210:01
66	323 359 40	Socket PG 29	1
