01 |
385 243 40
|
Tetra seal |
7 |
InternBDB: Bus. u. Luy. FR 76-6299-2200 | InternKon: 457 200 40 / 37
|
|
|
|
03 |
145 823 40
|
Half flange |
12 |
InternBDB: 50 /210 (2") | InternKon: 457 200 40 / 28
|
|
|
|
04 |
319 156 99
|
Bolt |
38 |
InternBDB: M12x30 /912 8.8 | InternKon: 457 200 40 / 88
|
|
|
|
05 |
324 527 40
|
Hose fittings, nipple |
4 |
InternBDB: Aeroquip G 4690-32 | InternKon: 457 200 40 / 158
|
|
|
|
06 |
324 526 40
|
Hose fittings, socket |
6 |
InternBDB: Aeroquip G 4010-32 | InternKon: 457 200 40 / 91
|
|
|
|
07 |
324 525 40
|
Hose DN 50x3250
Bulk ware, state length
required |
1 |
InternBDB: Aeroquip 2781-32 | InternKon: 457 200 40 / 12
|
|
|
|
08 |
324 536 40
|
Hose fittings, nipple |
2 |
InternBDB: Aeroquip G 4614-32 | InternKon: 457 200 40 / 49
|
|
|
|
09 |
324 525 40
|
Hose DN 50x3950
Bulk ware, state length
required |
1 |
InternBDB: Aeroquip 2781-32 | InternKon: 457 200 40 / 12
|
|
|
|
10 |
007 697 98
|
O-ring |
2 |
InternBDB: 011 745 99 69,4x3,5 B /90 | InternKon: 457 200 40 / 38
|
|
|
|
11 |
145 824 40
|
Half flange |
2 |
InternBDB: 60 /210 (2 1/2") | InternKon: 457 200 40 / 29
|
|
|
|
12 |
368 257 40
|
Hose fittings, nipple |
1 |
InternBDB: Aeroquip G 4679-40-32 | InternKon: 457 200 40 / 242
|
|
|
|
13 |
269 103 40
|
Hose NW 50x2550
Bulk ware, state length
required |
1 |
InternBDB: Aeroquip 2651-32 | InternKon: 457 200 40 / 166
|
|
|
|
14 |
324 451 40
|
Hose fittings, nipple |
1 |
InternBDB: Aeroquip G 4675-40-32 | InternKon: 457 200 40 / 73
|
|
|
|
15 |
368 256 40
|
Hose fittings, socket |
2 |
InternBDB: Aeroquip G 1212-32 | InternKon: 457 200 40 / 138
|
|
|
|
16 |
319 157 99
|
Bolt |
8 |
InternBDB: M12x35 /912 8.8 | InternKon: 457 200 40 / 188
|
|
|
|
17 |
534 009 99
|
Welding plate |
5 |
InternBDB: ES 6 011 839 99
|
|
|
|
18 |
502 371 98
|
Half clamp |
4 |
InternBDB: RI - CS 6
|
|
|
|
19 |
534 008 99
|
Cover plate |
5 |
InternBDB: DS 6
|
|
|
|
20 |
308 459 99
|
Bolt |
10 |
InternBDB: M12x100 /931 10.9
|
|
|
|
21 |
502 626 98
|
Grommet |
2 |
InternBDB: RI - Z6S / 56,4
|
|
|
|
22 |
505 058 98
|
Half clamp |
8 |
InternBDB: H-CS 6 /70
|
|
|
|
30 |
438 133 40
|
Manifold |
1 |
InternKon: 457 200 40 / 230
|
|
|
|
31 |
500 250 98
|
Bolt |
4 |
InternBDB: M12x155 /912 | InternKon: 457 200 40 / 231
|
|
|
|
32 |
504 786 98
|
Screw |
2 |
InternBDB: GS 6 011 839 99
|
|
|
|
33 |
504 787 98
|
Locking plate |
1 |
InternBDB: SS 6 /011 839 99
|
|
|
|
34 |
324 525 40
|
Hose DN 50x2950
Bulk ware, state length
required |
1 |
InternBDB: Aeroquip 2781-32 | InternKon: 457 200 40 / 12
|
|
