358 282 40
|
Hydr.-control block, assy. |
1 |
InternBDB: Rexroth MO-5539-00/ 4 MO-52 378 323 AT-Nr. 668 850
|
|
|
|
? |
|
Housing
These parts are not sold
separately |
1 |
InternBDB: 199 222 | InternKon: MO 5538-0-2-1 / 05
|
|
|
|
? |
319 260 99
|
Screw |
32 |
InternBDB: M10x50 /912 10.9 | InternKon: MO 5538-0-2-1 / 19
|
|
|
|
? |
754 567
|
Cover |
1 |
InternBDB: 685 767 | InternKon: MO 5538-0-2-1 / 6
|
|
|
|
? |
972 032
|
O-ring |
8 |
InternBDB: 101,2x3,53 | InternKon: MO 5538-0-2-1 / 38
|
|
|
|
? |
754 568
|
Pin |
8 |
InternBDB: 199 219 | InternKon: MO 5538-0-2-1 / 12
|
|
|
|
? |
504 811 98
|
Snap ring |
8 |
InternBDB: A 40 /7993 | InternKon: MO 5538-0-2-1 / 29
|
|
|
|
? |
754 569
|
Spring plate |
8 |
InternBDB: 199 220 | InternKon: MO 5538-0-2-1 / 11
|
|
|
|
? |
754 570
|
Spring |
8 |
InternBDB: 015 041 | InternKon: MO 5538-0-2-1 / 26
|
|
|
|
? |
754 571
|
Spring |
8 |
InternBDB: 015 040 | InternKon: MO 5538-0-2-1 / 25
|
|
|
|
? |
754 572
|
Spring plate |
8 |
InternBDB: 199 221 | InternKon: MO 5538-0-2-1 / 10
|
|
|
|
? |
754 573
|
Cover |
1 |
InternBDB: 685 766 | InternKon: MO 5538-0-2-1 / 7
|
|
|
|
? |
754 574
|
Piston
Procurement only by state-
ment of block-No. |
4 |
InternBDB: 300 894 | InternKon: MO 5538-0-2-1 / 8
|
|
|
|
? |
|
Pressure relief valve |
1 |
InternBDB: MHDB-40 K2- 1x/420M-019 381 589 | InternKon: MO 5538-0-2-1 / 15
|
090-0404 |
|
|
? |
994 304
|
Seal kit, to fig-no: 14 |
-2 |
InternBDB: 309 657
|
|
|
|
? |
313 504 99
|
Eyebolt |
3 |
InternBDB: M 20 /580 | InternKon: MO 5538-0-2-1 / 24
|
|
|
|
? |
319 276 99
|
Screw |
32 |
InternBDB: M12x60 /912 10.9 | InternKon: MO 5538-0-2-1 / 20
|
|
|
|
? |
754 576
|
Plate |
8 |
InternBDB: MO-7199 300 549 | InternKon: MO 5538-0-2-1 / 17
|
|
|
|
? |
756 344 73
|
Seal |
16 |
InternBDB: 003 340 26,3x33,5x2,2
|
|
|
|
? |
756 345 73
|
Support ring valid up to no: 35 |
16 |
InternBDB: MOV-4-1872
|
|
