01 |
358 681 40
|
Hydr.-pump, assy. |
1 |
InternBDB: Hydromatik A7F 0 107/60 L-DZB 11 421 499 AT-Nr. 668 842
|
|
|
|
02 |
|
Housing |
1 |
InternBDB: 417 785 | InternKon: 212.25.00.02 / 06
|
|
|
|
03 |
319 158 99
|
Screw |
7 |
InternBDB: M12x40 /912 | InternKon: 212.25.00.02 / 16
|
|
|
|
04 |
318 811 99
|
Screw |
1 |
InternBDB: M12x75 /912 | InternKon: 212.25.00.02 / 17
|
|
|
|
05 |
754 521
|
Connection plate |
1 |
InternBDB: 417 860 | InternKon: 212.25.00.02 / 02
|
|
|
|
06 |
344 841 99
|
Pin |
2 |
InternBDB: 10 M6x20 /7 | InternKon: 212.25.00.02 / 18
|
|
|
|
07 |
754 522
|
Gasket |
1 |
InternBDB: 413 489 | InternKon: 212.25.00.02 / 04
|
|
|
|
08 |
502 595 98
|
Thread pin |
1 |
InternBDB: M12x100 /915 12.9 153 975 | InternKon: 212.25.00.02 / 08
|
|
|
|
09 |
504 762 98
|
Thread pin |
1 |
InternBDB: M12x55 /913 12.9 | InternKon: 212.25.00.02 / 09
|
|
|
|
10 |
964 767
|
Nut |
2 |
InternBDB: M 12 152 459 | InternKon: 212.25.00.02 / 12
|
|
|
|
11 |
754 523
|
Regulation journal |
1 |
InternBDB: 417 865 | InternKon: 212.25.00.02 / 05
|
|
|
|
12 |
964 732
|
Plug |
3 |
InternBDB: vsti 18x1,5 ed /sa-1 153 815 | InternKon: 212.25.00.02 / 10
|
|
|
|
13 |
754 524
|
Transmission, assy.
fig-nos: 14,15,23,31-37 |
1 |
InternBDB: 421 498 + 419 659 | InternKon: 212.25.00.02 / 01
|
|
|
|
14 |
754 526
|
Control lense, l.h. execution |
1 |
InternBDB: 419 659 | InternKon: 212.25.00.02 / 03
|
|
|
|
15 |
754 525
|
Transmission, assy.
fig-nos: 16-22 |
1 |
InternBDB: 410 390
|
|
|
|
16 |
754 527
|
Cylinder |
1 |
InternBDB: 410 290 | InternKon: 201.25.03.90 / 01
|
|
|
|
17 |
754 528
|
Spring plate |
1 |
InternBDB: 412 570 | InternKon: 201.25.03.90 / 06
|
|
|
|
18 |
753 765
|
Cup spring |
4 |
InternBDB: 409 134 | InternKon: 201.25.03.90 / 07
|
|
|
|
19 |
754 529
|
Trunnion |
1 |
InternBDB: 410 289 | InternKon: 201.25.03.90 / 03
|
|
|
|
20 |
754 530
|
Piston with piston ring |
7 |
InternBDB: 410 321 + 2x 156 248 | InternKon: 201.25.03.90 / 04
|
|
|
|
21 |
753 599
|
Screw, burnished |
14 |
InternBDB: 153 617 M5x16 /7985 | InternKon: 201.25.03.90 / 12
|
|
|
|
22 |
998 761
|
Withdrawal plate |
1 |
InternBDB: 062 574 | InternKon: 201.25.03.90 / 11
|
|
|
|
23 |
754 531
|
Drive shaft with bearing set
with fig-nos: 24-30 |
1 |
InternBDB: 270 742
|
|
|
|
24 |
|
Roller bearing
These parts are not sold
separately |
1 |
InternBDB: T 7 FC 070 DIN/ISO 355 154 344 | InternKon: 201.25.03.15 / 10
|
|
|
|
25 |
|
Shim ring 110x140x0,2
These parts are not sold
separately |
2 |
InternBDB: 154 260 | InternKon: 201.25.03.15 / 17
|
|
|
|
26 |
|
Shim ring 110x140x0,3
These parts are not sold
separately |
1 |
InternBDB: 087 601 | InternKon: 201.25.03.15 / 18
|
|
|
|
27 |
|
Shim ring 110x140x0,5
These parts are not sold
separately |
1 |
InternBDB: 154 259 | InternKon: 201.25.03.15 / 19
|
|
|
|
28 |
|
Taper Roller bearing
These parts are not sold
separately |
1 |
InternBDB: 152 775 / 502 088 98 | InternKon: 201.25.03.15 / 11
|
|
|
|
29 |
|
Race
These parts are not sold
separately |
1 |
InternBDB: 410 429 | InternKon: 201.25.03.15 / 03
|
|
|
|
30 |
|
Groove nut
These parts are not sold
separately |
1 |
InternBDB: GUK 65x2 156 102 | InternKon: 201.25.03.15 / 05
|
|
|
|
31 |
342 678 99
|
Circlip |
1 |
InternBDB: 140x4 /472 | InternKon: 201.25.03.15 / 12
|
|
|
|
32 |
754 532
|
Disk |
1 |
InternBDB: 110x140x3,5 156 292 | InternKon: 201.25.03.15 / 06
|
|
|
|
33 |
971 053
|
O-ring |
1 |
InternBDB: 132,95,3,53 252-7507 | InternKon: 201.25.03.15 / 15
|
|
|
|
34 |
951 976
|
Shaft seal |
2 |
InternBDB: 60x80x7 BABSL 0,5 084 369 | InternKon: 201.25.03.15 / 14
|
|
|
|
35 |
754 533
|
Disk |
1 |
InternBDB: 63x80 087 019 | InternKon: 201.25.03.15 / 07
|
|
|
|
36 |
754 534
|
Cover |
1 |
InternBDB: 410 498 | InternKon: 201.25.03.15 / 04
|
|
|
|
37 |
754 535
|
Snap ring |
1 |
InternBDB: SB 140 154 380 | InternKon: 201.25.03.15 / 13
|
|
|
|
|$$38 |
754 536
|
Repair kit, assy.
fig-nos. 07,10,12,33-36 |
-2 |
InternBDB: E-ST
|
|
|
|
|$$39 |
973 125
|
Fluid sealing to fig-no: 21 50 ml |
-2 |
InternBDB: Loctite 241
|
|
|
|
|$$40 |
989 946
|
Fluid sealing (pipe thread) 50 ml (Rohrgewinde) |
-2 |
InternBDB: Loctite 572
|
|
