01 |
|
Pump distributor gear |
1 |
InternKon: 366 599 40 / 22
|
090-2079b |
|
|
02 |
304 368 99
|
Bolt |
8 |
InternBDB: M30x160 /931 | InternKon: 366 599 40 / 5
|
|
|
|
03 |
366 592 40
|
Bush |
8 |
InternKon: 366 599 40 / 11
|
|
|
|
04 |
332 361 99
|
Nut |
16 |
InternBDB: M 30 /934 | InternKon: 366 599 40 / 8
|
|
|
|
10 |
269 870 40
|
Cover tube |
1 |
InternBDB: Noris MX2 /R12 R 1/2" | InternKon: 399 790 40 / 8
|
|
|
|
11 |
323 249 40
|
Temperature indicator |
1 |
InternBDB: Noris TH 31 40 ?-120 ? | InternKon: 399 790 40 / 6
|
|
|
|
15 |
600 909 99
|
Reducing nut |
1 |
InternBDB: HPG 11-9
|
|
|
|
16 |
502 921 98
|
Reducing nut |
1 |
InternBDB: HPG 9-7
|
|
|
|
17 |
323 949 40
|
Hose union |
1 |
InternBDB: 5010.100.007
|
|
|
|
18 |
323 954 40
|
Plug-in sleeve |
1 |
InternBDB: 5031.028.007
|
|
|
|
19 |
056 211 40
|
Conduit 4500 mm
Bulk ware, state length required |
-2 |
|
|
|
|
20 |
501 606 98
|
Cable 5000 mm
Bulk ware, state length required |
-2 |
|
|
|
|
21 |
|
Retainer |
4 |
|
|
|
|
22 |
|
Clamp |
4 |
|
|
|
|
23 |
|
Bolt |
4 |
|
|
|
|
24 |
|
Nut |
4 |
|
|
|
|
30 |
490 636 40
|
Ball cock DN 40 |
1 |
InternBDB: Zentgraf K33-11/2 NPT
|
|
|
|
31 |
374 415 99
|
Socket |
1 |
InternBDB: L42M /3901
|
|
|
|
32 |
372 178 99
|
Union |
1 |
InternBDB: DDL42 /2353
|
|
|
|
33 |
507 123 98
|
Union |
1 |
InternBDB: EVGE42-L/11/2 NPT 011 576 99
|
|
|
|
34 |
372 479 99
|
Socket |
1 |
InternBDB: GE42-L/11/2 NPT 010 880 99
|
|
|
|
35 |
371 860 99
|
Plug |
1 |
InternBDB: BUZ42-L 011 638 99
|
|
