01 |
|
Air cleaner |
2 |
InternBDB: 414 984 40 | InternKon: 366 576 40 / 4
|
090-5581 |
|
|
02 |
366 577 40
|
Plate |
1 |
InternKon: 366 576 40 / 7
|
|
|
|
03 |
366 572 40
|
Carrier |
1 |
InternKon: 366 576 40 / 1
|
|
|
|
04 |
366 568 40
|
Support |
1 |
InternKon: 366 576 40 / 2
|
|
|
|
05 |
366 584 40
|
Thread plate |
1 |
InternKon: 366 576 40 / 14
|
|
|
|
06 |
366 585 40
|
Thread plate |
1 |
InternKon: 366 576 40 / 15
|
|
|
|
07 |
343 116 99
|
Lock washer |
6 |
InternBDB: 16 /128 | InternKon: 366 576 40 / 23
|
|
|
|
08 |
307 822 99
|
Bolt |
3 |
InternBDB: M16x30 /933 | InternKon: 366 576 40 / 19
|
|
|
|
09 |
307 821 99
|
Bolt |
3 |
InternBDB: M16x25 /933 | InternKon: 366 576 40 / 20
|
|
|
|
10 |
534 063 99
|
Bolt |
32 |
InternBDB: 5/8-11 UNC x 1 3/4 /10.9 010 500 99 | InternKon: 366 576 40 / 21
|
|
|
|
11 |
341 211 99
|
Washer |
32 |
InternBDB: 18 /434 | InternKon: 366 576 40 / 24
|
|
|
|
12 |
308 641 99
|
Bolt |
5 |
InternBDB: M16x130 /931 | InternKon: 366 576 40 / 18
|
|
|
|
13 |
365 442 40
|
Bush |
5 |
InternKon: 366 576 40 / 16
|
|
|
|
14 |
332 336 99
|
Nut |
5 |
InternBDB: M 16 /934 | InternKon: 366 576 40 / 22
|
|
|
|
20 |
370 753 99
|
Twin nipple |
4 |
InternBDB: 1/8 /2990
|
|
|
|
21 |
370 690 99
|
Elbow union |
4 |
InternBDB: 1/8 /2987 | InternKon: 366 576 40 / 31
|
|
|
|
22 |
372 446 99
|
Union |
4 |
InternBDB: DL 6 /2353 | InternKon: 366 576 40 / 32
|
|
|
|
23 |
215 622 99
|
Pipe Ш 6x150 mm
Bulk ware, state length
required |
4 |
InternBDB: 6x1 /2391
|
|
|
|
24 |
145 895 40
|
Maintenance switch |
4 |
InternBDB: Ma. u. Hu. 390 006 2901
|
|
|
|
25 |
440 151 99
|
Receptacle for tabs |
4 |
InternBDB: He. u. Bu. 50.252.510
|
|
|
|
26 |
|
Insulation sleeve |
4 |
InternBDB: He. u. Bu. 50.251.562
|
|
|
|
27 |
323 954 40
|
Plug-in sleeve |
4 |
InternBDB: Sievert 5031.028.007
|
|
|
|
28 |
056 211 40
|
Conduit
Bulk ware, state length
required |
-2 |
InternBDB: Sievert 2010.101.007
|
|
|
|
29 |
502 609 98
|
Cable 1 qmm blue
Bulk ware, state length
required |
-2 |
InternBDB: H07V-K1x1,5 blau
|
|
|
|
30 |
006 300 98
|
Clamp |
20 |
InternBDB: RSGU 1100 10/15
|
|
|
|
31 |
|
Nut |
20 |
InternBDB: M 4 /934
|
|
|
|
32 |
370 500 99
|
Union |
4 |
InternBDB: CL 6 /2353 | InternKon: 366 576 40 / 33
|
|
