01 |
654 461 40
|
Circulation pump |
1 |
InternBDB: Hamworthy PC 2419 C 4 B 26 A | InternKon: 675 375 40 / 1
|
|
|
|
02 |
675 373 40
|
Block |
1 |
InternKon: 675 375 40 / 2
|
|
|
|
03 |
389 860 40
|
Intake |
1 |
InternKon: 675 375 40 / 3
|
|
|
|
04 |
006 633 98
|
Half flange |
2 |
InternBDB: 32 /210 | InternKon: 675 375 40 / 4
|
|
|
|
05 |
385 742 40
|
Seal |
1 |
InternKon: 675 375 40 / 5
|
|
|
|
06 |
513 401 98
|
Hose assy. DN 40 x 800 |
1 |
InternBDB: FL 2 | InternKon: 675 375 40 / 6
|
|
|
|
07 |
513 402 98
|
Hose assy. DN 20 x 7200 |
1 |
InternBDB: DOS 25 / FL 1 1/4-90 | InternKon: 675 375 40 / 7
|
|
|
|
08 |
005 860 98
|
Clamp |
1 |
InternBDB: 1S 58x15 | InternKon: 675 375 40 / 8
|
|
|
|
09 |
006 635 98
|
Half flange |
2 |
InternBDB: 50 /210 | InternKon: 675 375 40 / 9
|
|
|
|
10 |
385 243 40
|
Flange seal |
1 |
InternBDB: 2 | InternKon: 675 375 40 / 10
|
|
|
|
11 |
356 210 40
|
Seal |
2 |
InternBDB: 1 1/4 | InternKon: 675 375 40 / 11
|
|
|
|
12 |
319 430 99
|
Bolt |
4 |
InternBDB: M10x50 /912 | InternKon: 675 375 40 / 12
|
|
|
|
13 |
319 157 99
|
Bolt |
4 |
InternBDB: M12x35 /912 | InternKon: 675 375 40 / 13
|
|
|
|
14 |
319 158 99
|
Bolt |
4 |
InternBDB: M12x40 /912 | InternKon: 675 375 40 / 14
|
|
|
|
15 |
334 600 99
|
Nut |
4 |
InternBDB: M 12 /985 | InternKon: 675 375 40 / 15
|
|
|
|
16 |
007 697 98
|
O-ring |
2 |
InternBDB: 69,4 x 3,53 | InternKon: 675 375 40 / 16
|
|
|
|
18 |
371 357 99
|
Return valve |
1 |
InternBDB: RHD 25-S | InternKon: 675 375 40 / 21
|
|
|
|
19 |
371 943 99
|
Union |
1 |
InternBDB: EVGE 25-S | InternKon: 675 375 40 / 20
|
|
|
|
20 |
372 186 99
|
Union |
1 |
InternBDB: DDS 25 | InternKon: 675 375 40 / 19
|
|
|
|
22 |
153 646 40
|
Coupling |
1 |
InternBDB: AG 1/4-PC | InternKon: 675 375 40 / 22
|
|
|
|
23 |
654 502 40
|
Flange |
1 |
InternBDB: Havit 1 1/4 | InternKon: 675 375 40 / 23
|
|
|
|
24 |
319 186 99
|
Bolt |
2 |
InternBDB: M16x35 /912 | InternKon: 675 375 40 / 24
|
|
|
|
25 |
340 410 99
|
Washer |
2 |
InternBDB: 17 /433 | InternKon: 675 375 40 / 25
|
|
