01 |
440 890 40
|
H.P. filter assy. |
1 |
InternBDB: Argo HD 510-22 05 33 003 AT-Nr. 669 400 73
|
|
|
|
02 |
696 494 73
|
Filter head |
1 |
InternBDB: 300 7457
|
|
|
|
03 |
695 997 73
|
Element assy. |
2 |
InternBDB: 168 4003 S9.0817-22
|
|
|
|
04 |
504 765 98
|
O-ring |
2 |
InternBDB: 320 5083 44,2x2,5 /80
|
|
|
|
05 |
694 420
|
Compression spring |
2 |
InternBDB: 320 8501
|
|
|
|
06 |
972 149
|
O-ring |
2 |
InternBDB: 320 5178 94,85x3,53/ 80
|
|
|
|
07 |
694 423
|
Support ring |
2 |
InternBDB: 461 9017
|
|
|
|
08 |
695 998 73
|
Filter housing |
2 |
InternBDB: 372 3231
|
|
|
|
09 |
334 000 99
|
Seal ring |
2 |
InternBDB: 333 1081 A21x26x3/ 7603
|
|
|
|
10 |
313 458 99
|
Plug |
2 |
InternBDB: 330 6009 M20x1,5 /908
|
|
|
|
11 |
696 495 73
|
Different. pressure switch assy. (8,5 bar) |
2 |
InternBDB: 080 2008-02 DG 021-05 Z2
|
|
|
|
12 |
972 150
|
O-ring |
4 |
InternBDB: 320 5001 4,5x1,5
|
|
|
|
13 |
696 496 73
|
Gasket |
2 |
InternBDB: 320 6022
|
|
|
|
14 |
697 292 73
|
Elbow plug |
2 |
InternBDB: 3333 001
|
|
|
|
15 |
696 498 73
|
Locking spring |
2 |
InternBDB: 301 8030
|
|
|
|
16 |
343 092 99
|
Lock washer |
8 |
InternBDB: 331 5001 B 4 /127
|
|
|
|
17 |
319 409 99
|
Screw |
8 |
InternBDB: 330 2001 M4x30 /912
|
|
