01 |
694 630
|
Pipe, assy. Ш 65 |
1 |
InternBDB: 371 580 40 | InternKon: 641 300 40 / 188
|
|
|
|
02 |
694 631
|
Pipe, assy. Ш 65 |
1 |
InternBDB: 371 579 40 | InternKon: 641 300 40 / 187
|
|
|
|
03 |
694 632
|
Pipe, assy. Ш 65 |
1 |
InternBDB: 371 578 40 | InternKon: 641 300 40 / 186
|
|
|
|
04 |
694 633
|
Pipe, assy. Ш 65 |
1 |
InternBDB: 371 577 40 | InternKon: 641 300 40 / 185
|
|
|
|
05 |
504 448 98
|
Flange |
8 |
InternBDB: FE-6500-32/6 | InternKon: 641 300 40 / 44
|
|
|
|
06 |
385 243 40
|
Tetra seal |
12 |
InternBDB: Bu. u. Lu. FR 76-6299 -2200 2" | InternKon: 641 300 40 / 54
|
|
|
|
07 |
504 461 98
|
Collar ring |
4 |
InternBDB: K-6580-32 | InternKon: 641 300 40 / 50
|
|
|
|
08 |
319 323 99
|
Screw |
16 |
InternBDB: M20x90 /912 10.9 | InternKon: 641 300 40 / 45
|
|
|
|
09 |
504 449 98
|
Collar ring |
4 |
InternBDB: KO-6580-32 | InternKon: 641 300 40 / 51
|
|
|
|
10 |
319 313 99
|
Screw |
16 |
InternBDB: M20x120 /912 10.9 | InternKon: 641 300 40 / 46
|
|
|
|
11 |
343 117 99
|
Lock washer |
-2 |
InternBDB: 20 /128
|
|
|
|
12 |
332 338 99
|
Nut |
32 |
InternBDB: M 20 /934 | InternKon: 641 300 40 / 47
|
|
|
|
13 |
319 305 99
|
Screw |
16 |
InternBDB: M20x60 /912 10.9 | InternKon: 641 300 40 / 39
|
|
|
|
14 |
371 519 40
|
Hose, assy. DN 50x1500 lg. |
4 |
InternBDB: TL | InternKon: 641 300 40 / 96
|
|
|
|
15 |
534 009 99
|
Welding plate |
4 |
InternBDB: ES 6 011 839 99
|
|
|
|
16 |
500 034 98
|
Half clamp |
8 |
InternBDB: CS 6/65
|
|
|
|
17 |
534 008 99
|
Cover plate |
4 |
InternBDB: DS 6
|
|
|
|
18 |
308 459 99
|
Bolt |
8 |
InternBDB: M12x100 /931
|
|
|
|
20 |
510 908 98
|
Hose assy. DN 25x7600 lg. |
1 |
InternBDB: DOL 28 / DOL 28-90 | InternKon: 641 300 40 / 142
|
|
|
|
21 |
623 447 40
|
Hose assy. DN 25x8600 lg. |
1 |
InternBDB: DOL 28 / DOL 28-90 | InternKon: 641 300 40 / 137
|
|
|
|
22 |
534 020 99
|
Welding plate |
5 |
InternBDB: E 5
|
|
|
|
23 |
534 019 99
|
Half clamp |
10 |
InternBDB: C 5/38
|
|
|
|
24 |
340 405 99
|
Washer |
10 |
InternBDB: 6,4 /433
|
|
|
|
25 |
319 136 99
|
Screw |
10 |
InternBDB: M6x50 /912
|
|
|
|
26 |
374 434 99
|
Socket |
1 |
InternBDB: S 12 M /3901 | InternKon: 641 300 40 / 82
|
|
|
|
29 |
510 933 98
|
Hose DN 10x9100 lg. |
1 |
InternBDB: DOL 12-90 / DOS 12 | InternKon: 641 300 40 / 126
|
|
|
|
31 |
374 431 99
|
Socket |
4 |
InternBDB: L 28 M /3901 | InternKon: 641 300 40 / 61
|
|
|
|
34 |
372 176 99
|
Union |
2 |
InternBDB: DDL 28 /2353
|
|
