01 |
623 473 40
|
Hose assy. DN 50x3900 lg. |
12 |
InternBDB: FS2 /FS2 WN 341 951 40 | InternKon: 598 101 40 / 90
|
|
|
|
02 |
385 243 40
|
Quad seal ring |
24 |
InternBDB: FR 76-6299-2200 | InternKon: 598 101 40 / 54
|
|
|
|
03 |
319 305 99
|
Bolt |
48 |
InternBDB: M20x60 /912 10.9 | InternKon: 598 101 40 / 39
|
|
|
|
05 |
607 653 40
|
Clamping retainer |
2 |
InternKon: 598 105 40 / 1
|
|
|
|
06 |
385 822 40
|
Retainer |
1 |
InternKon: 607 653 40 / 1
|
|
|
|
08 |
505 010 98
|
Bolt |
24 |
InternBDB: M16x170 /931 10.9 | InternKon: 607 653 40 / 5
|
|
|
|
09 |
504 853 98
|
Clamp |
12 |
InternBDB: S-5-E/3015 | InternKon: 607 653 40 / 3
|
|
|
|
10 |
505 212 98
|
Grommet |
12 |
InternBDB: S-5-68/3015 | InternKon: 607 653 40 / 7
|
|
|
|
11 |
500 398 98
|
Cover plate |
11 |
InternBDB: S-DP-A-5 | InternKon: 607 653 40 / 4
|
|
|
|
12 |
332 355 99
|
Nut |
48 |
InternBDB: M16 /934 | InternKon: 607 653 40 / 6
|
|
|
|
13 |
502 618 98
|
Clamp |
1 |
InternBDB: S-3-E/3015 | InternKon: 607 653 40 / 8
|
|
|
|
14 |
504 926 98
|
Grommet |
1 |
InternBDB: S-3-32/3015 | InternKon: 607 653 40 / 9
|
|
|
|
15 |
509 440 40
|
Plate |
1 |
InternKon: 607 653 40 / 2
|
|
|
|
16 |
534 004 99
|
Cover plate |
1 |
InternBDB: S-DP-A-3/3015 | InternKon: 607 653 40 / 10
|
|
|
|
17 |
308 581 99
|
Bolt |
2 |
InternBDB: M10x70 /931 | InternKon: 607 653 40 / 11
|
|
|
|
18 |
343 005 99
|
Washer |
2 |
InternBDB: 10,5 /93 | InternKon: 607 653 40 / 12
|
|
