01 |
604 119 40
|
Connecting plate NG 6 |
1 |
InternBDB: Rexroth 5 HSR 06-2X /02 C | InternKon: 623 475 40 / 1
|
|
|
|
02 |
256 425 40
|
4/2-Directional spool valve |
2 |
InternBDB: 4 WE 6C 50 AG 24 NZ 4 | InternKon: 623 475 40 / 2
|
|
|
|
03 |
490 079 40
|
Non-return valve NG 6 |
2 |
InternBDB: Z1S 6P1-3X/V | InternKon: 623 475 40 / 3
|
|
|
|
04 |
551 467 40
|
Pressure relief valve |
1 |
InternBDB: ZDB 6 VB 2-4x50V | InternKon: 623 475 40 / 4
|
|
|
|
06 |
324 634 40
|
Three-way pressure valve |
1 |
InternBDB: 3 DREP 6 A10/25 A 24 NZ 4 M | InternKon: 623 475 40 / 6
|
|
|
|
07 |
490 080 40
|
Blank plate NG 6 |
2 |
InternBDB: 316 232 | InternKon: 623 475 40 / 7
|
|
|
|
08 |
502 286 98
|
Screw |
4 |
InternBDB: M5x130 /912 10.9 | InternKon: 623 475 40 / 8
|
|
|
|
09 |
502 732 98
|
Screw |
4 |
InternBDB: M5x90 /912 10.9 | InternKon: 623 475 40 / 9
|
|
|
|
10 |
319 174 99
|
Screw |
4 |
InternBDB: M5x50 /912 10.9 | InternKon: 623 475 40 / 10
|
|
|
|
11 |
319 125 99
|
Screw |
8 |
InternBDB: M5x30 /912 8.8 | InternKon: 623 475 40 / 11
|
|
|
|
12 |
500 287 98
|
O-ring |
32 |
InternBDB: 9,25x1,78
|
|
|
|
13 |
971 231
|
O-ring |
6 |
|
|
|
|
14 |
502 461 98
|
Screw |
8 |
InternBDB: M4x65 /912
|
|
|
|
15 |
319 553 99
|
Screw |
4 |
InternBDB: M5x60 /912
|
|
|
|
16 |
763 687 73
|
Cover |
1 |
InternBDB: 318 095
|
|
|
|
17 |
763 688 73
|
Compression spring |
2 |
InternBDB: 013 029
|
|
|
|
18 |
763 689 73
|
Spring plate |
2 |
InternBDB: 170 977
|
|
|
|
19 |
763 690 73
|
Shim ring |
1 |
InternBDB: 006 951
|
|
|
|
20 |
763 691 73
|
Piston |
1 |
InternBDB: 170 990
|
|
|
|
21 |
763 692 73
|
Pin |
2 |
InternBDB: 164 330
|
|
|
|
22 |
319 552 99
|
Screw |
4 |
InternBDB: M5x12 /912 8.8
|
|
|
|
23 |
515 210 40
|
Valve plug |
4 |
InternBDB: Murr MSUD-1U24-15-B 246 340
|
|
|
|
24 |
756 414 73
|
Housing |
2 |
InternBDB: 153 194
|
|
|
|
25 |
756 412 73
|
Washer |
4 |
InternBDB: 149 806
|
|
|
|
26 |
763 693 73
|
Compression spring |
4 |
InternBDB: 001 489
|
|
|
|
27 |
763 694 73
|
Piston |
2 |
InternBDB: 150 264
|
|
|
|
28 |
756 408 73
|
Cover |
2 |
InternBDB: 152 060
|
|
|
|
29 |
318 614 99
|
Screw |
8 |
InternBDB: M4x16 /912 8.8
|
|
|
|
30 |
756 102 73
|
Rubber cap |
2 |
InternBDB: 009 300
|
|
|
|
31 |
763 695 73
|
Housing |
2 |
InternBDB: 166 399
|
|
|
|
32 |
763 696 73
|
Bushing |
2 |
InternBDB: 167 822
|
|
|
|
33 |
763 697 73
|
Compression spring |
2 |
InternBDB: 012 275
|
|
|
|
34 |
763 698 73
|
Taper |
2 |
InternBDB: 167 635
|
|
|
|
35 |
511 072 98
|
O-ring |
2 |
InternBDB: 008 205 9x1,5
|
|
|
|
36 |
763 700 73
|
Support ring |
2 |
InternBDB: 013 064
|
|
|
|
37 |
763 701 73
|
Housing |
1 |
InternBDB: 682 893
|
|
|
|
38 |
763 702 73
|
Plate |
2 |
InternBDB: 127 443
|
|
|
|
39 |
757 932 73
|
Pressure relief valve |
1 |
InternBDB: DB 6 K2-4x/y
|
|
|
|
40 |
348 648 40
|
Seal |
2 |
InternBDB: Hirschmann GDM 3-17
|
|
