01 |
654 116 40
|
Return oil filter |
1 |
InternBDB: Fa. Hydac 00404775 W.0 mit Schutzrohr 701 mm LG
|
|
|
|
02 |
694 400
|
Element assy. |
1 |
InternBDB: 00402 990, Profildichtung 2x Hydac Nr. 1203152 | InternKon: / 1
|
|
|
|
03 |
694 409
|
Element assy.
incl. fig no.: 04 |
1 |
InternBDB: 00402 990 | InternKon: / 2
|
|
|
|
04 |
501 288 98
|
O-ring |
1 |
InternBDB: 68x5/80
|
|
|
|
05 |
763 933 73
|
Cover |
1 |
InternBDB: 0120 2934 | InternKon: 2.2 / 4.4 / 3
|
|
|
|
06 |
696 670 73
|
Seal . |
1 |
InternBDB: 4.412.271
|
|
|
|
07 |
958 615
|
Seal |
1 |
InternBDB: 14,7x22x1,5 | InternKon: 2.2 / 4.4 / 4.3
|
|
|
|
08 |
101 484 65
|
O-ring |
1 |
InternBDB: 15x2/80 | InternKon: 2.2 / 4.4 / 4.5
|
|
|
|
09 |
334 694 99
|
Nut |
1 |
InternBDB: M14/985 | InternKon: 2.2 / 4.4 / 5.1
|
|
|
|
10 |
334 627 99
|
Nut |
2 |
InternBDB: M 10 / 985 | InternKon: 2.2 / 4.4 / 5.2
|
|
|
|
11 |
763 795 73
|
Element buffering piece
incl. fig no.: 12 |
1 |
InternBDB: 0126 2709 | InternKon: 2.2 / 4.4 / 6
|
|
|
|
12 |
694 945
|
Compression sring |
1 |
InternBDB: 606.715 | InternKon: 2.2 / 4.4 / 6.2
|
|
|
|
13 |
763 796 73
|
Element retainer |
1 |
InternBDB: 0126 2737 | InternKon: 2.2 / 4.4 / 7
|
|
|
|
|$$14 |
763 794 73
|
Seal kit assy.
incl. fig nos.: 04,06,07,08 |
1 |
InternBDB: 0126 2675 | InternKon: 2.2 / 4.4 / 4
|
|
