01 |
358 693 40
|
Hose, assy. DN 40x1210 lg. |
1 |
InternBDB: TL | InternKon: 457 200 40 / 105
|
|
|
|
02 |
358 692 40
|
Hose, assy. DN 50x1880 lg. |
1 |
InternBDB: TL | InternKon: 457 200 40 / 104
|
|
|
|
03 |
358 691 40
|
Hose, assy. DN 50x2360 lg. |
1 |
InternBDB: TL | InternKon: 457 200 40 / 103
|
|
|
|
04 |
414 490 40
|
Hose, assy. DN 40x2670 lg. |
1 |
InternBDB: TL | InternKon: 457 200 40 / 106
|
|
|
|
06 |
385 243 40
|
Tetra seal |
5 |
InternBDB: Bu. u. Lu. FR 76-6299- 2200 2" | InternKon: 457 200 40 / 37
|
|
|
|
08 |
319 305 99
|
Screw |
20 |
InternBDB: M20x60 /912 10.9 | InternKon: 457 200 40 / 176
|
|
|
|
10 |
319 288 99
|
Screw |
12 |
InternBDB: M16x50 /912 10.9 | InternKon: 457 200 40 / 173
|
|
|
|
11 |
356 209 40
|
Tetra seal |
3 |
InternBDB: Bu. u. Lu. FR-76-5937- 2200 1 1/2" | InternKon: 457 200 40 / 36
|
|
|
|
12 |
534 009 99
|
Welding plate |
1 |
InternBDB: ES 6 011 839 99 | InternKon: 396 112 40 / 36
|
|
|
|
13 |
502 371 98
|
Half clamp |
2 |
InternBDB: RI-CS 6 | InternKon: 396 112 40 / 22
|
|
|
|
14 |
534 008 99
|
Cover plate |
1 |
InternBDB: DS 6 | InternKon: 396 112 40 / 37
|
|
|
|
15 |
308 459 99
|
Bolt |
2 |
InternBDB: M12x100 /931 10.9 | InternKon: 396 112 40 / 49
|
|
|
|
16 |
502 626 98
|
Grommet |
1 |
InternBDB: RI-Z6S/56,4 | InternKon: 396 112 40 / 24
|
|
