01 |
368 297 40
|
Hose assy. DN 40x1700 |
1 |
InternBDB: 350 FS 1 1/2 FS 1 1/2 90 | InternKon: 647 801 40 / 14
|
|
|
|
02 |
331 513 40
|
Hose assy. DN 40x1200 |
2 |
InternBDB: 350 FS 1 1/2 FS 1 1/2 90 | InternKon: 647 801 40 / 15
|
|
|
|
03 |
356 209 40
|
Flange seal |
8 |
InternBDB: 1 1/2 NBR 90 | InternKon: 647 801 40 / 39
|
|
|
|
04 |
319 288 99
|
Bolt |
32 |
InternBDB: M16x50 /912 10.9 | InternKon: 647 801 40 / 40
|
|
|
|
10 |
608 723 40
|
Manifold |
1 |
InternKon: 574 555 40 / 04
|
|
|
|
12 |
506 581 98
|
Plug |
2 |
InternBDB: SAE A 1 1/2-6000 | InternKon: 574 555 40 / 32
|
|
|
|
13 |
319 288 99
|
Bolt |
8 |
InternBDB: M16x50 /912 10.9 | InternKon: 574 555 40 / 33
|
|
|
|
14 |
763 531 73
|
Pipe assy. Ш 65 |
1 |
InternBDB: 650 346 40 | InternKon: 574 555 40 / 13
|
|
|
|
15 |
763 532 73
|
Pipe assy. Ш 65 |
1 |
InternBDB: 650 347 40 | InternKon: 574 555 40 / 14
|
|
|
|
16 |
504 448 98
|
Flange |
4 |
InternBDB: FE-6500-32/6 | InternKon: 574 555 40 / 22
|
|
|
|
17 |
504 461 98
|
Ring |
4 |
InternBDB: K-6580-32 | InternKon: 574 555 40 / 23
|
|
|
|
18 |
385 243 40
|
Flange seal |
6 |
InternBDB: 2 NBR 90 | InternKon: 574 555 40 / 24
|
|
|
|
19 |
319 323 99
|
Bolt |
16 |
InternBDB: M20x90 /912 | InternKon: 574 555 40 / 25
|
|
|
|
25 |
389 480 40
|
Distribution block |
1 |
InternKon: 637 574 40 / 10
|
|
|
|
26 |
389 481 40
|
Connector plate |
1 |
InternKon: 637 574 40 / 11
|
|
|
|
27 |
320 153 99
|
Bolt |
4 |
InternBDB: M20x55 /912 10.9 | InternKon: 637 574 40 / 18
|
|
|
|
28 |
308 887 99
|
Bolt |
4 |
InternBDB: M20x160 /931 10.9 | InternKon: 637 574 40 / 19
|
|
|
|
30 |
308 413 99
|
Bolt |
3 |
InternBDB: M20x180 | InternKon: TT 637 551 40 / 42
|
|
|
|
31 |
316 212 99
|
Washer |
3 |
InternBDB: 21 / 6916 | InternKon: TT 637 551 40 / 43
|
|
|
|
32 |
512 318 98
|
Hose assy. DN 40x2100 |
1 |
InternBDB: 350 FS 1 1/2 FS 1 1/2 90
|
|
